Sony STR-V919 - Printed Wiring Board - SPEAKER Section

STR-DE925/V919
— 33 —
— 34 —
3-14. PRINTED WIRING BOARD — SPEAKER SECTION — • See page 7 for Circuit Boards Location.
12
A
B
C
D
E
F
G
H
I
J
345678910111213
H
Q
UVX
N
M
1-670-002-
11
(11)
1-670-035-
11
(11)
SP BOARD
REAR AMP BOARD
WOOFER
REAR
CENTER
IMPEDANCE SELECTOR
14
1
15
6
E
E
E
E
E
E
E
E
EE
1
3
4-8
TM701
WIRELESS REAR
SPEAKER
13
E
E
BC E BC E BC E B
B
CCE
E
E
E
B
CE
16
16
Q609
(Page26)
(Page13)
(Page14)
(Page14)
(Page25)
(Page43)
(Page13)
Ref. No. Location
• Semiconductor
Location
D543 I-5
D605 H-8
D606 H-9
D607 I-9
D649 G-5
D701 C-12
D702 C-12
D703 C-11
D704 B-11
D705 I-4
D706 I-4
D749 G-2
D751 C-5
D752 C-5
D753 C-3
D754 B-4
IC702 G-11
Q544 I-6
Q609 G-9
Q610 H-9
Q611 H-9
Q645 G-8
Q704 C-12
Q705 B-11
Q706 B-13
Q707 B-10
Q708 C-14
Q709 I-3
Q710 I-3
Q745 I-7
Q747 G-9
Q748 G-10
Q754 C-4
Q755 B-4
Q756 B-5
Q757 B-3
Q758 B-2
