SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian MY : Malaysia
AUS : Australian SP : Singapore
CH : Chinese EA : Saudi Arabia
AC AMPLIFIER
* 1-669-998-11 AC BOARD
********
1-533-217-31 HOLDER, FUSE
< JACK >
! CNJ901 1-540-060-11 OUTLET, AC (POLAR) (US,CND,E,EA,PX)
! CNJ901 1-540-041-11 OUTLET, AC (NONPOLAR) (2P) (CH)
< CONNECTOR >
* CNP905 1-580-230-21 PIN, CONNECTOR (PC BOARD) 2P (MY,SP)
CNP915 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CNV901 1-564-321-00 PIN, CONNECTOR 2P
* CNV902 1-565-792-11 PIN, CONNECTOR 2P
CNV903 1-568-106-11 PIN, CONNECTOR 4P (E,EA,PX)
< DIODE >
D907 8-719-911-19 DIODE 1SS119
< EARTH >
* EB900 1-537-738-21 TERMINAL, EARTH
< FUSE >
! F901 1-532-504-51 FUSE TIME LAG 4A (E,EA,MY,SP,CH,PX)
! F901 1-533-311-11 FUSE, GLASS CYLINDRICAL(DIA.5) 8A
(US,CND)
! F903 1-532-464-51 FUSE TIME LAG 2.5A (MY,SP,CH)
! F904 1-532-504-51 FUSE TIME LAG 4A (E,EA,PX)
< RELAY >
! RY901 1-515-999-11 RELAY, POWER
< RESISTOR >
! R901 1-202-725-00 SOLID 3.3M 10% 1/2W (US,CND)
< TRANSFORMER >
! T902 1-450-361-11 TRANSFORMER, POWER (US,CND)
! T902 1-431-387-11 TRANSFORMER, POWER (E,EA,MY,SP,CH,PX)
< SWITCH >
! VS901 1-571-437-11 SWITCH, POWER VOLTAGE CHANGE (E,EA,PX)
************************************************************
* A-4414-061-A AMPLIFIER BOARD, COMPLETE
(US,CND,E,EA,PX)
**************************************
* A-4414-128-A AMPLIFIER BOARD, COMPLETE (CH)
******************************
* A-4414-085-A AMPLIFIER BOARD, COMPLETE (MY,SP)
*********************************
1-533-293-11 FUSE HOLDER
< CAPACITOR >
C520 1-126-022-11 ELECT 47uF 20% 16V
C521 1-107-597-11 CERAMIC 22PF 10% 500V
C522 1-107-597-11 CERAMIC 22PF 10% 500V
C523 1-162-286-31 CERAMIC 220PF 10% 50V
C524 1-126-059-11 ELECT 10uF 20% 50V
C525 1-136-161-00 FILM 0.047uF 5% 50V
(CH,SP,MY)
C526 1-136-153-00 FILM 0.01uF 5% 50V
C527 1-136-161-00 FILM 0.047uF 5% 50V
(CH,SP,MY)
C570 1-126-022-11 ELECT 47uF 20% 16V
C571 1-107-597-11 CERAMIC 22PF 10% 500V
C572 1-107-597-11 CERAMIC 22PF 10% 500V
C573 1-162-286-31 CERAMIC 220PF 10% 50V
C574 1-126-059-11 ELECT 10uF 20% 50V
C575 1-136-161-00 FILM 0.047uF 5% 50V
(CH,SP,MY)
C576 1-136-153-00 FILM 0.01uF 5% 50V
C577 1-136-161-00 FILM 0.047uF 5% 50V
(CH,SP,MY)
C590 1-124-472-11 ELECT 470uF 20% 10V
C598 1-126-233-11 ELECT 22uF 20% 50V
C620 1-126-022-11 ELECT 47uF 20% 16V
C621 1-107-597-11 CERAMIC 22PF 10% 500V
C622 1-107-597-11 CERAMIC 22PF 10% 500V
C623 1-162-286-31 CERAMIC 220PF 10% 50V
C625 1-136-161-00 FILM 0.047uF 5% 50V
(CH,SP,MY)
C627 1-136-161-00 FILM 0.047uF 5% 50V
(CH,SP,MY)
C801 1-104-664-11 ELECT 47uF 20% 25V
C803 1-109-932-11 ELECT(BLOCK) 10000uF 20% 71V
(US,CND,E,EA,PX)
C803 1-125-895-11 CAPACITOR 12000uF 20% 71V
(MY,SP,CH)
C804 1-109-932-11 ELECT(BLOCK) 10000uF 20% 71V
(US,CND,E,EA,PX)
C804 1-125-895-11 CAPACITOR 12000uF 20% 71V
(MY,SP,CH)
C805 1-130-781-00 FILM 0.22uF 10% 100V
C806 1-130-781-00 FILM 0.22uF 10% 100V
C807 1-126-967-11 ELECT 47uF 20% 50V
C808 1-126-967-11 ELECT 47uF 20% 50V
C811 1-126-041-11 ELECT 2200uF 20% 35V
C812 1-126-105-11 ELECT 1000uF 20% 35V
To Next Page
