Sony STR-V919 - Page 35

— 57 —
Pin No.
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
I/O DescriptionPin Name
DISPMR
DISPDATA
SLV DTA/REQ
VCC
DISP CLK
LAT
DATA
CLK
—
DATA IN
AUSTOP
STEREO
VSS
STOP
CCB/SUB
EMPHA
ERROR
SUB 1
SUB 2
—
—
@U@/CED
—
—
SRDT
SWDT
XLAT
SCLK
PROTEC
VIDEO-INH
VIDEO-A
VIDEO-B
VIDEO-E
ACMUTE
FUNMUTE
HSTX
MD 2
MD 1
MD 0
RESET
VSS
X 0
X 1
VCC
P 00
P 01
TUNER MUT
SURR MUT
7E/8E
—
I
I
O
—
I
O
O
O
—
I
I
I
—
I
I
I
O
I
I
—
—
I
—
—
I
O
O
O
I
O
O
O
O
O
O
—
—
—
—
I
—
—
—
—
I
I
O
O
I
—
Display master request (Connected to MB90553 U.MREQ)
Display data (Connected to MB90553 U.DATA)
Slave data/request (Connected to MB90553 U.SREQ)
Power supply +5 V
Display clock (Connected to MB90553 U.CLOCK)
To tuner TM301 latch
To tuner TM301 data
To tuner TM301 clock
Not used (Connected to GND)
PLL data input
Auto stop input
Stereo input
GND (Connected to GND)
AC power check
Not used (Connected to GND)
Not used (Connected to GND)
Error output to CXD8495AQ
Not used (Connected to GND)
Not used (Connected to GND)
Not used (Connected to GND)
Not used (Connected to GND)
U or CED (STR only)
Not used (Not connected, open)
Not used (Not connected, open)
To CXD8495AQ C-bit
To CXD8495AQ data
To CXD8495AQ latch
To CXD8495AQ clock
Protector input
Video output inhibit
To NJM2296 video select A
To NJM2296 video select B
To NJM2296 video select E
IC muting
Function muting
Hardware standby (Connected to power supply +5 V)
MD2 (To MB90553 MD2)
MD1 (Connect to power supply)
MD0 (To MB90553 MD0)
Reset (Connected to MB90553 U.RESET)
GND (Connected to GND)
External ceramic filter 4 MHz is connected to this terminal
External ceramic filter 4 MHz is connected to this terminal
Power supply +5 V
Flash memory rewrite (Connected to GND)
Flash memory rewrite (Connected to GND)
Tuner muting
Surround muting (Connected to GND)
Not used (Connected to GND)
Not used (Connected to GND)
