Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 69 —
D.IN/OUT DIGITAL
< RESISTOR >
R315 1-249-417-11 CARBON 1K 5% 1/4W F
R316 1-249-417-11 CARBON 1K 5% 1/4W F
R317 1-249-417-11 CARBON 1K 5% 1/4W F
R318 1-249-417-11 CARBON 1K 5% 1/4W F
R319 1-249-417-11 CARBON 1K 5% 1/4W F
R320 1-249-417-11 CARBON 1K 5% 1/4W F
R365 1-249-417-11 CARBON 1K 5% 1/4W F
R366 1-249-417-11 CARBON 1K 5% 1/4W F
R367 1-249-417-11 CARBON 1K 5% 1/4W F
R368 1-249-417-11 CARBON 1K 5% 1/4W F
R369 1-249-417-11 CARBON 1K 5% 1/4W F
R370 1-249-417-11 CARBON 1K 5% 1/4W F
R394 1-249-397-11 CARBON 22 5% 1/4W F
R395 1-249-397-11 CARBON 22 5% 1/4W F
R398 1-249-417-11 CARBON 1K 5% 1/4W F
R399 1-249-425-11 CARBON 4.7K 5% 1/4W F
************************************************************
* 1-670-029-11 D.IN/OUT BOARD
**************
< CAPACITOR >
C1001 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1002 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1003 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1004 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1005 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1006 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1007 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1008 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1009 1-104-664-11 ELECT 47uF 20% 16V
< CONNECTOR >
CNS13 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
< IC >
IC1001 8-749-923-05 IC TORX178 (DVD/LD IN)
IC1002 8-749-923-05 IC TORX178 (TV/DBS IN)
IC1003 8-749-923-05 IC TORX178 (MD/DAT IN)
IC1004 8-749-923-04 IC TOTX178 (MD/DAT OUT)
IC1005 8-759-236-19 IC TC74HC151AF(EL)
IC1006 8-759-235-19 IC TC74HC08AF(EL)
IC1007 8-759-242-70 IC TC7WU04F
< JACK >
J1001 1-779-382-11 JACK, PIN 1P (DVD/LD IN)
< RESISTOR >
R1001 1-216-022-00 METAL CHIP 75 5% 1/10W
R1002 1-216-022-00 METAL CHIP 75 5% 1/10W
R1003 1-216-022-00 METAL CHIP 75 5% 1/10W
R1004 1-216-022-00 METAL CHIP 75 5% 1/10W
R1005 1-216-025-91 RES,CHIP 100 5% 1/10W
R1006 1-216-025-91 RES,CHIP 100 5% 1/10W
R1007 1-216-025-91 RES,CHIP 100 5% 1/10W
R1008 1-216-022-00 METAL CHIP 75 5% 1/10W
R1009 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1010 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1011 1-216-025-91 RES,CHIP 100 5% 1/10W
R1013 1-216-115-00 METAL CHIP 560K 5% 1/10W
************************************************************
* A-4414-079-A DIGITAL BOARD, COMPLETE
***********************
< CAPACITOR >
C1101 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1102 1-126-022-11 ELECT 47uF 20% 16V
C1103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1104 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1105 1-126-022-11 ELECT 47uF 20% 16V
C1106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1107 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1108 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1109 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1110 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1111 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1112 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1113 1-126-059-11 ELECT 10uF 20% 50V
C1114 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1115 1-126-059-11 ELECT 10uF 20% 50V
C1116 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1118 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1119 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1120 1-126-059-11 ELECT 10uF 20% 50V
C1121 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1122 1-126-233-11 ELECT 22uF 20% 50V
C1123 1-106-347-00 MYLAR 1500PF 5% 200V
C1124 1-126-233-11 ELECT 22uF 20% 50V
C1125 1-126-233-11 ELECT 22uF 20% 50V
C1126 1-126-233-11 ELECT 22uF 20% 50V
C1127 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1128 1-126-233-11 ELECT 22uF 20% 50V
C1129 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1130 1-126-233-11 ELECT 22uF 20% 50V
C1131 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1132 1-126-233-11 ELECT 22uF 20% 50V
C1133 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1134 1-126-233-11 ELECT 22uF 20% 50V
C1135 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1136 1-126-233-11 ELECT 22uF 20% 50V
C1137 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1138 1-126-233-11 ELECT 22uF 20% 50V
C1139 1-126-022-11 ELECT 47uF 20% 16V
C1140 1-126-022-11 ELECT 47uF 20% 16V
C1142 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1170 1-126-059-11 ELECT 10uF 20% 50V
C1171 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1172 1-126-233-11 ELECT 22uF 20% 50V
C1173 1-106-347-00 MYLAR 1500PF 5% 200V
C1174 1-126-233-11 ELECT 22uF 20% 50V
C1175 1-126-233-11 ELECT 22uF 20% 50V
C1176 1-126-233-11 ELECT 22uF 20% 50V
C1201 1-126-059-11 ELECT 10uF 20% 50V
C1202 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1203 1-165-319-11 CERAMIC CHIP 0.1uF 50V
