Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 77 —
* 1-670-007-11 LED BOARD
*********
< DIODE >
D100 8-719-070-83 DIODE SELU5E20C-TP15
************************************************************
* A-4414-112-A REAR AMP BOARD, COMPLETE
************************
< CAPACITOR >
C720 1-126-022-11 ELECT 47uF 20% 16V
C721 1-107-597-11 CERAMIC 22PF 10% 500V
C722 1-107-597-11 CERAMIC 22PF 10% 500V
C723 1-162-286-31 CERAMIC 220PF 10% 50V
C725 1-136-157-00 FILM 0.022uF 5% 50V
C770 1-126-022-11 ELECT 47uF 20% 16V
C771 1-107-597-11 CERAMIC 22PF 10% 500V
C772 1-107-597-11 CERAMIC 22PF 10% 500V
C773 1-162-286-31 CERAMIC 220PF 10% 50V
C775 1-136-157-00 FILM 0.022uF 5% 50V
< CONNECTOR >
* CNP701 1-564-241-11 PIN, CONNECTOR (B4P-VH) 4P
CNP711 1-779-977-11 PIN, CONNECTOR 6P
* CNP712 1-564-242-00 PIN, CONNECTOR 5P
CNP713 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< DIODE >
D701 8-719-911-19 DIODE 1SS119
D702 8-719-109-51 DIODE RD2.0ES-B2
D703 8-719-109-51 DIODE RD2.0ES-B2
D704 8-719-911-19 DIODE 1SS119
D751 8-719-911-19 DIODE 1SS119
D752 8-719-109-51 DIODE RD2.0ES-B2
D753 8-719-109-51 DIODE RD2.0ES-B2
D754 8-719-911-19 DIODE 1SS119
< TRANSISTOR >
Q704 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q708 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q754 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q758 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
< RESISTOR >
R702 1-247-881-00 CARBON 120K 5% 1/4W
R721 1-249-433-11 CARBON 22K 5% 1/4W
R722 1-249-422-11 CARBON 2.7K 5% 1/4W F
R723 1-249-414-11 CARBON 560 5% 1/4W F
! R724 1-249-408-11 CARBON 180 5% 1/4W F
! R725 1-249-408-11 CARBON 180 5% 1/4W F
! R726 1-233-352-41 ENCAPSULATED COMPONENT
R727 1-247-850-11 CARBON 6.2K 5% 1/4W
R728 1-249-419-11 CARBON 1.5K 5% 1/4W F
R732 1-249-437-11 CARBON 47K 5% 1/4W
! R733 1-249-393-11 CARBON 10 5% 1/4W F
R752 1-247-881-00 CARBON 120K 5% 1/4W
R771 1-249-433-11 CARBON 22K 5% 1/4W
R772 1-249-422-11 CARBON 2.7K 5% 1/4W F
R773 1-249-414-11 CARBON 560 5% 1/4W F
! R774 1-249-408-11 CARBON 180 5% 1/4W F
! R775 1-249-408-11 CARBON 180 5% 1/4W F
! R776 1-233-352-41 ENCAPSULATED COMPONENT
R777 1-247-850-11 CARBON 6.2K 5% 1/4W
R778 1-249-419-11 CARBON 1.5K 5% 1/4W F
R782 1-249-437-11 CARBON 47K 5% 1/4W
! R783 1-249-393-11 CARBON 10 5% 1/4W F
************************************************************
* A-4414-109-A REG BOARD, COMPLETE
*******************
1-533-217-31 HOLDER, FUSE
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C819 1-136-165-00 FILM 0.1uF 5% 50V
C820 1-136-165-00 FILM 0.1uF 5% 50V
C821 1-136-165-00 FILM 0.1uF 5% 50V
C822 1-136-165-00 FILM 0.1uF 5% 50V
C823 1-136-165-00 FILM 0.1uF 5% 50V
C824 1-126-937-11 ELECT 4700uF 20% 16V
C825 1-126-935-11 ELECT 470uF 20% 16V
C826 1-126-935-11 ELECT 470uF 20% 16V
C827 1-126-935-11 ELECT 470uF 20% 16V
C901 1-164-097-11 CERAMIC 0.022uF 50V
C902 1-164-097-11 CERAMIC 0.022uF 50V
C903 1-126-768-11 ELECT 2200uF 20% 16V
C904 1-126-960-11 ELECT 1uF 20% 50V
C905 1-126-959-11 ELECT 0.47uF 20% 50V
C906 1-124-464-11 ELECT 0.22uF 20% 50V
C911 1-164-159-11 CERAMIC 0.1uF 50V
C914 1-164-159-11 CERAMIC 0.1uF 50V
C916 1-164-159-11 CERAMIC 0.1uF 50V
C917 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP803 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
CNP809 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D808 8-719-025-03 DIODE RBA-402-SL
D901 8-719-024-99 DIODE 11ES2-NTA2B
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-911-19 DIODE 1SS119
D906 8-719-911-19 DIODE 1SS119
< EARTH >
* EB901 1-537-738-21 TERMINAL,
< FUSE >
! F805 1-532-504-51 FUSE TIME LAG 4A (E,EA,MY,SP,CH,PX)
! F805 1-533-419-11 FUSE,GLASS CYLINDRICAL(DIA.5)4A(US,CND)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
REGREAR AMPLED
To Next Page
