– 64 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
D639 8-719-046-44 DIODE SEL5221S (DSP DELAY)
D640 8-719-046-44 DIODE SEL5221S (DSP REVERB)
D641 8-719-046-44 DIODE SEL5221S () +)
D642 8-719-058-04 DIODE SEL5223S-TP15 (MULTI JOG STATION)
< TRANSISTOR >
Q531 8-729-900-80 TRANSISTOR DTC114ES
Q532 8-729-900-80 TRANSISTOR DTC114ES
Q533 8-729-900-80 TRANSISTOR DTC114ES
Q534 8-729-900-80 TRANSISTOR DTC114ES
Q535 8-729-900-80 TRANSISTOR DTC114ES
Q538 8-729-900-80 TRANSISTOR DTC114ES
Q539 8-729-900-80 TRANSISTOR DTC114ES
Q540 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R631 1-249-410-11 CARBON 270 5% 1/4W F
R632 1-249-410-11 CARBON 270 5% 1/4W F
R633 1-247-807-31 CARBON 100 5% 1/4W
R634 1-249-410-11 CARBON 270 5% 1/4W F
R635 1-249-416-11 CARBON 820 5% 1/4W F
R638 1-249-416-11 CARBON 820 5% 1/4W F
R639 1-249-416-11 CARBON 820 5% 1/4W F
R640 1-249-416-11 CARBON 820 5% 1/4W F
R641 1-247-807-31 CARBON 100 5% 1/4W
R642 1-249-407-11 CARBON 150 5% 1/4W F
R643 1-249-409-11 CARBON 220 5% 1/4W F
R644 1-249-411-11 CARBON 330 5% 1/4W
R645 1-249-411-11 CARBON 330 5% 1/4W
R646 1-249-413-11 CARBON 470 5% 1/4W F
R647 1-249-415-11 CARBON 680 5% 1/4W F
R648 1-249-417-11 CARBON 1K 5% 1/4W F
R649 1-249-419-11 CARBON 1.5K 5% 1/4W F
R650 1-249-421-11 CARBON 2.2K 5% 1/4W F
R651 1-247-843-11 CARBON 3.3K 5% 1/4W
R652 1-249-417-11 CARBON 1K 5% 1/4W F
R653 1-247-807-31 CARBON 100 5% 1/4W
R654 1-249-407-11 CARBON 150 5% 1/4W F
R655 1-249-409-11 CARBON 220 5% 1/4W F
R656 1-249-411-11 CARBON 330 5% 1/4W
R657 1-249-411-11 CARBON 330 5% 1/4W
R658 1-249-413-11 CARBON 470 5% 1/4W F
R659 1-249-415-11 CARBON 680 5% 1/4W F
R660 1-249-429-11 CARBON 10K 5% 1/4W
R661 1-249-429-11 CARBON 10K 5% 1/4W
R662 1-249-429-11 CARBON 10K 5% 1/4W
R663 1-249-429-11 CARBON 10K 5% 1/4W
R665 1-247-843-11 CARBON 3.3K 5% 1/4W
R666 1-247-843-11 CARBON 3.3K 5% 1/4W
R671 1-247-807-31 CARBON 100 5% 1/4W
R672 1-247-807-31 CARBON 100 5% 1/4W
R673 1-247-807-31 CARBON 100 5% 1/4W
R674 1-247-807-31 CARBON 100 5% 1/4W
R675 1-247-807-31 CARBON 100 5% 1/4W
R678 1-247-807-31 CARBON 100 5% 1/4W
R679 1-247-807-31 CARBON 100 5% 1/4W
R680 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S631 1-762-378-11 SWITCH, TACTILE (0 –)
S632 1-762-378-11 SWITCH, TACTILE (GAME)
S633 1-762-378-11 SWITCH, TACTILE (MUSIC)
S634 1-762-378-11 SWITCH, TACTILE (MOVIE)
S635 1-762-378-11 SWITCH, TACTILE (DSP DELAY)
S636 1-762-378-11 SWITCH, TACTILE (CD REPEAT)
S637 1-762-378-11 SWITCH, TACTILE (FLASH)
S638 1-762-378-11 SWITCH, TACTILE (DSP REVERB)
S639 1-762-378-11 SWITCH, TACTILE (CD PLAY MODE)
S640 1-762-378-11 SWITCH, TACTILE (CD EDIT)
S641 1-762-378-11 SWITCH, TACTILE (NON-STOP)
S642 1-762-378-11 SWITCH, TACTILE (DBFB)
S643 1-762-378-11 SWITCH, TACTILE (ENTER/NEXT)
S644 1-762-378-11 SWITCH, TACTILE () +)
S645 1-762-378-11 SWITCH, TACTILE (GROOVE)
S648 1-762-378-11 SWITCH, TACTILE (EFFECT ON/OFF)
S649 1-762-378-11 SWITCH, TACTILE (P FILE)
S650 1-762-378-11 SWITCH, TACTILE (PLACE)
S651 1-762-378-11 SWITCH, TACTILE (LOOP)
S652 1-473-392-11 ENCODER, ROTARY (VOLUME)
S653 1-467-968-11 ENCODER, ROTARY (MULTI JOG STAION)
**************************************************************
* A-4414-190-A MAIN BOARD, COMPLETE (AEP,UK)
********************
* A-4414-198-A MAIN BOARD, COMPLETE
********************
(E,EA3(Malaysia Product),SP,MY,AR,TW,AUS,CH)
* A-4414-549-A MAIN BOARD, COMPLETE (EE,CIS)
********************
* A-4414-714-A MAIN BOARD, COMPLETE
********************
(EA3(Japan Product),JE)
* A-4414-765-A MAIN BOARD, COMPLETE (EA4,TH)
********************
< CAPACITOR >
C101 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP,UK)
C103 1-126-963-11 ELECT 4.7uF 20% 50V
C104 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP,UK)
C105 1-164-159-11 CERAMIC 0.1uF 50V
C108 1-126-960-11 ELECT 1uF 20% 50V
C111 1-136-171-00 FILM 0.33uF 5% 50V
C112 1-136-161-00 FILM 0.047uF 5% 50V
C113 1-164-159-11 CERAMIC 0.1uF 50V
C114 1-130-480-00 MYLAR 0.0056uF 5% 50V
C115 1-136-159-00 FILM 0.033uF 5% 50V
C116 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C117 1-162-306-11 CERAMIC 0.01uF 20% 16V
C118 1-162-290-31 CERAMIC 470PF 10% 50V
C119 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C120 1-162-302-11 CERAMIC 0.0022uF 20% 16V
LOADING PANEL MAIN
