– 63 –
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
EE : East European model.
EA3 : Saudi Arabia model
EA4 : Israel model
EA : Middle East model
(Saudi Arabia and Israel)
SP : Singapore model.
MY : Malaysia model.
TW : Taiwan model
AUS : Australian model.
CH : Chinese model
AR : Argentine model
JE : Tourist model
TH : Thai model.
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
SECTION 7
ELECTRICAL PARTS LIST
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
LOADING PANEL
HEADPHONE
* 1-669-964-11 DETECTOR BOARD
***************
< CONNECTOR >
* CN505 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S892 1-571-300-21 SWITCH, ROTARY (PANEL OPEN/CLOSE)
**************************************************************
* 1-669-957-11 FRONT AV BOARD
**************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C6301 1-162-282-31 CERAMIC 100PF 10% 50V
C6302 1-162-282-31 CERAMIC 100PF 10% 50V
C6303 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
* CN6301 1-564-520-11 PLUG, CONNECTOR 5P
* CN6302 1-560-666-00 PIN, CONNECTOR 3P
< DIODE >
D6301 8-719-911-19 DIODE 1SS119-25
D6302 8-719-911-19 DIODE 1SS119-25
D6303 8-719-911-19 DIODE 1SS119-25
< JACK >
J6301 1-784-901-11 JACK, PIN 3P (AV INPUT (VIDEO2))
< TRANSISTOR >
Q6301 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R6301 1-249-417-11 CARBON 1K 5% 1/4W F
R6302 1-249-417-11 CARBON 1K 5% 1/4W F
R6303 1-249-441-11 CARBON 100K 5% 1/4W
R6304 1-249-441-11 CARBON 100K 5% 1/4W
R6305 1-249-425-11 CARBON 4.7K 5% 1/4W F
R6306 1-249-425-11 CARBON 4.7K 5% 1/4W F
R6307 1-249-425-11 CARBON 4.7K 5% 1/4W F
R6308 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
* 1-669-960-11 HEADPHONE BOARD
***************
< CAPACITOR >
C790 1-162-306-11 CERAMIC 0.01uF 20% 16V
C791 1-162-294-31 CERAMIC 0.001uF 10% 50V
C792 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
* CN790 1-568-944-11 PIN, CONNECTOR 6P
< EARTH >
* G790 1-537-738-21 TERMINAL, EARTH
< JACK >
J755 1-770-226-11 JACK (LARGE TYPE)(PHONES)
**************************************************************
* 1-669-959-11 LOADING PANEL BOARD
*******************
< CAPACITOR >
C626 1-124-584-00 ELECT 100uF 20% 10V
C627 1-162-306-11 CERAMIC 0.01uF 20% 16V
C628 1-162-306-11 CERAMIC 0.01uF 20% 16V
C629 1-162-306-11 CERAMIC 0.01uF 20% 16V
C630 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN630 1-569-308-11 SOCKET, CONNECTOR (L TYRE) 19P
< DIODE >
D631 8-719-046-39 DIODE SEL5821A-TH15 (GROOVE)
D632 8-719-046-44 DIODE SEL5221S (0 –)
D633 8-719-058-04 DIODE SEL5223S-TP15 (MULTI JOG STATION)
D634 8-719-046-44 DIODE SEL5221S (ENTER/NEXT)
D635 8-719-046-44 DIODE SEL5221S (EFFECT ON/OFF)
D638 8-719-046-44 DIODE SEL5221S (NON-STOP)
FRONT AVDETECTOR
