Sony STR-W555 - Page 52

– 68 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C6016 1-126-967-11 ELECT 47uF 20% 16V
(EA3(Japan Product),JE)
C6017 1-164-159-11 CERAMIC 0.1uF 50V
(EA3(Japan Product),JE)
C6018 1-126-967-11 ELECT 47uF 20% 16V
(EA3(Japan Product),JE)
C6019 1-136-495-11 FILM 0.068uF 5% 50V
(EA3(Japan Product),JE)
C6020 1-162-305-11 CERAMIC 0.0068uF 30% 16V
(EA3(Japan Product),JE)
C6021 1-162-294-31 CERAMIC 0.001uF 10% 50V
(EA3(Japan Product),JE)
C6022 1-124-257-00 ELECT 2.2uF 20% 50V
(EA3(Japan Product),JE)
C6023 1-161-494-00 CERAMIC 0.022uF 25V
(EA3(Japan Product),JE)
C6024 1-136-167-00 FILM 0.15uF 5% 50V
(EA3(Japan Product),JE)
C6025 1-126-957-11 ELECT 0.22uF 20% 50V
(EA3(Japan Product),JE)
C6026 1-126-957-11 ELECT 0.22uF 20% 50V
(EA3(Japan Product),JE)
C6027 1-136-495-11 FILM 0.068uF 5% 50V
(EA3(Japan Product),JE)
C6028 1-162-294-31 CERAMIC 0.001uF 10% 50V
(EA3(Japan Product),JE)
C6029 1-162-305-11 CERAMIC 0.0068uF 30% 16V
(EA3(Japan Product),JE)
C6031 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN6001 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D6001 8-719-911-19 DIODE 1SS119-25 (EA3(Japan Product),JE)
D6002 8-719-911-19 DIODE 1SS119-25 (EA3(Japan Product),JE)
D6003 8-719-911-19 DIODE 1SS119-25 (EA3(Japan Product),JE)
< EARTH >
* E6001 1-537-738-21 TERMINAL, EARTH
< IC >
IC6001 8-759-634-51 IC M5218AP
IC6002 8-759-450-96 IC M65850P (EA3(Japan Product),JE)
< JACK >
J6001 1-770-226-11 JACK (LARGE TYPE)
(MIX MIC:EXCEPT EA3(Japan Product),JE)(MIC1:EA3(Japan Product),JE)
J6002 1-750-733-11 JACK (LARGE TYPE)(MIC2)
(EA3(Japan Product),JE)
< COIL >
L6011 1-410-521-11 INDUCTOR 100uH
(EA3(Japan Product),JE)
< RESISTOR >
R6001 1-249-429-11 CARBON 10K 5% 1/4W
R6002 1-249-417-11 CARBON 1K 5% 1/4W F
R6003 1-249-429-11 CARBON 10K 5% 1/4W
(EA3(Japan Product),JE)
R6004 1-249-417-11 CARBON 1K 5% 1/4W F
(EA3(Japan Product),JE)
R6005 1-249-441-11 CARBON 100K 5% 1/4W
R6006 1-249-417-11 CARBON 1K 5% 1/4W F
R6007 1-249-433-11 CARBON 22K 5% 1/4W
R6008 1-249-429-11 CARBON 10K 5% 1/4W
R6009 1-247-885-00 CARBON 180K 5% 1/4W
R6010 1-247-807-31 CARBON 100 5% 1/4W
R6011 1-249-433-11 CARBON 22K 5% 1/4W
(EA3(Japan Product),JE)
R6012 1-247-881-00 CARBON 120K 5% 1/4W
(EA3(Japan Product),JE)
R6013 1-249-433-11 CARBON 22K 5% 1/4W
(EA3(Japan Product),JE)
R6014 1-249-433-11 CARBON 22K 5% 1/4W
(EA3(Japan Product),JE)
R6015 1-249-433-11 CARBON 22K 5% 1/4W
(EA3(Japan Product),JE)
R6016 1-249-429-11 CARBON 10K 5% 1/4W F
(EA3(Japan Product),JE)
R6017 1-249-437-11 CARBON 47K 5% 1/4W
(EA3(Japan Product),JE)
R6018 1-249-433-11 CARBON 22K 5% 1/4W
(EA3(Japan Product),JE)
R6019 1-249-433-11 CARBON 22K 5% 1/4W
(EA3(Japan Product),JE)
R6020 1-249-431-11 CARBON 15K 5% 1/4W
(EA3(Japan Product),JE)
< VARIABLE RESISTOR >
RV6001 1-225-410-11 RES, VAR, CARBON 50K (MIC LEVEL)
(EXECEPT EA3(Japan Product), JE)
RV6001 1-225-511-21 RES, VAR, CARBON 50K/50K
(MIC LEVEL, ECHO LEVEL)(EA3(Japan Product),JE)
**************************************************************
* 1-669-965-11 MOTOR BOARD
***********
< CAPACITOR >
C891 1-162-306-11 CERAMIC 0.01uF 20% 16V
C892 1-124-478-11 ELECT 100uF 20% 25V
C893 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN892 1-568-941-11 PIN, CONNECTOR 3P
< DIODE >
D891 8-719-947-16 DIODE MTZJ-T-72-5.1A
< IC >
IC891 8-759-822-09 IC LB1641
< RESISTOR >
R891 1-249-425-11 CARBON 4.7K 5% 1/4W F
R892 1-249-425-11 CARBON 4.7K 5% 1/4W F
R893 1-249-429-11 CARBON 10K 5% 1/4W
R894 1-249-413-11 CARBON 470 5% 1/4W F
**************************************************************
MIC/ECHO MOTOR
