[D] System Configuration – SYSTEM CONFIGURATION Menu
Chapter 2 Menu
The factory settings for each pin
1 PIN: CH01
2 PIN: CH02
3 PIN: EXT SYNC
4 PIN: MONO
5 PIN: MARKER
6 PIN: unused
7 PIN: unused
8 PIN: TALLY
[D211] PARALLEL REMOTE menu
PARALLEL REMOTE (1/2) menu
CH01 to 30: Select a channel number. Enter the
desired channel number with the numeric button.
----: Set to unused.
UNDER SCAN: Set under scan on or off.
16:9: Set a 16:9 aspect ratio on or off.
H DELAY: Set the horizontal sync display on or off.
V DELAY: Set the vertical sync display on or off.
EXT SYNC: Set the synchronization to external sync
signals enabled or disabled.
COMB: Set the comb filter on or off.
APERTURE: Set the correction of frequency
characteristics enabled or disabled.
MONO: Set monochrome display on or off.
PARALLEL REMOTE (2/2) menu
BLUE ONLY: Set the blue signal pictures display
(monochrome) on or off.
R OFF: Set cutting red beams enabled or disabled.
G OFF: Set cutting green beams enabled or disabled.
B OFF: Set cutting blue beams enabled or disabled.
CHROMA UP: Set 12 dB up of the chroma setting
value on or off.
MARKER: Set the marker set in the channel on or off.
TALLY: Set tally lamp on or off.
DEGAUSS: Set degaussing on or off.
POWER OFF: Set the monitor power on or standby.
For the pin assignment, see “PARALLEL REMOTE
connector” in Location and Function of Parts on page 12.
[D3] POWER... menu
Set the condition of the monitor when the main power is
turned on or the power is turned on by remote operation.
STANDBY MODE: Select the power-up condition
(OFF or ON) when the MAIN POWER switch is
turned on.
OFF: Operation mode (default)
ON: Standby mode
POWER ON STATUS: Select the power-up input
channel (LAST or CH).
LAST: Set the channel to the channel that was
selected at the time the power was last turned off
(default).
CH: Set the channel to a specific channel number.
DEFAULT CH: Select the channel (01 to 30) when
the POWER ON STATUS is set to CH (default
setting is 01).
DEGAUSS DELAY: Set the period from the time
when the picture is almost displayed to the
beginning of degaussing (000 to 255) (default
setting is 000). Enter the desired time (in seconds).
[D4] BLANKING SETTINGS... menu
Adjust the data for the blanking.
ANCILLARY DATA: Select whether or not to
display the ancillary data in the serial digital signal
(OFF or ON) (default setting is ON).
VITS BLK: Adjust vertical blanking so that VITS
signals are not visible in the upper part of the
screen.
Set to 000 to 127 (default setting is 000).
[D5] ON SCREEN SET... menu
Set the data about the screen display.
FORMAT DISPLAY: Select the display mode of the
signal system.
AUTO: Disappears after being displayed for a
while (default).
ON: Displayed.
OFF: Not displayed.
POSITION: Select the display position for the signal
system.
TOP LEFT, TOP CENTER, TOP RIGHT,
BOTTOM LEFT (default), BOTTOM CENTER,
BOTTOM RIGHT
CH NO: Select the display mode of the channel
number
AUTO: Disappears after being displayed for a
while (default).
ON: Displayed.
OFF: Not displayed.
POSITION: Select the display position for the
channel number.
TOP LEFT, TOP CENTER, TOP RIGHT (default),
BOTTOM LEFT, BOTTOM CENTER, BOTTOM
RIGHT
CH NAME: Select the display mode of the channel
name
AUTO: Disappears after being displayed for a
while (default).
To Next Page
