55
[G] Displaying Information On the Monitor – STATUS Menu
Chapter 2 Menu
Setting Lists in the STATUS Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
For purposes of explanation, each setting list is preceded
by a menu number. These numbers are not displayed on
the screen.
For more information on the menu numbers, see “About
menu numbers” on page 26.
The arrow mark (k) refers you to another setting list
that appears after you make the setting, or to an operation
that is to be carried out as a result of the setting.
[G] STATUS menu
Select the STATUS (1/2) menu or STATUS (2/2) menu.
STATUS (1/2) menu
CH STATUS...: Display the information of the used
channel. k[G1]
SLOT STATUS...: Display the type of OPTION 1 to
3. k[G2]
HD-SDI/D1...: Display when BKM-61D is
installed.
SDI/COMPOSITE...: Display when BKM-62HS
is installed.
COMPONENT...: Display when BKM-68X is
installed.
EMPTY...: Display when no adaptor is installed.
STATUS (2/2) menu
Data on the monitor and controller is displayed.
MODEL NAME: Model name of the monitor
SERIAL NO: Serial number of the monitor
SOFTWARE VERSION: Software version of the
monitor
OPERATION TIME: Operation time (in hours) of
the monitor
CRT TURN ON TIME: Used time of the CRT (in
hours)
IP ADDR: IP address of the monitor
When the NETWORK switch is set to PEER TO
PEER, “192.168.000.001” is displayed.
CONTROLLER STATUS...: Information on the
controller k[G3]
[G1] CH STATUS... menu
Display the information on the used channel.
The information of the assigned internal signal is displayed
on the channels 80 to 89 and 91 to 97.
CH: Channel number
OP: Option slot number (OPTION1 to 3)
IN: Input connector number
FORMAT: Input signal format
NAME: Channel name
The information of the internal signal is displayed
in channels 80 to 89 and 91 to 97.
[G2] SLOT STATUS menu
Display the type of input adaptor installed in OPTION1 to
3.
MODEL NAME: Model name
SERIAL NO: Serial number
[G3] CONTROLLER STATUS... menu
Display information on the controller.
MODEL NAME: Model name
SERIAL NO: Serial number
SOFTWARE VERSION: Software version
IP ADDR: IP address
When the NETWORK switch is set to PEER TO
PEER, “192.168.000.100” is displayed.
Note
Note
