Sony Trinitron BVM-A32E1WU - Dimensional Drawing

63
Specifications
Appendixes
Dimensional Drawing
Unit: mm (inches)
Front
Side
Rear
Bottom
793.9 (31
3
/8)
555.4
(21
7
/8)
531.4
(21)
24
(
31
/32)
719.9 (28
3
/8)
694 (27
3
/8)
510 (20
1
/8)
76.4
(3
1
/8)
28
(1
1
/8)
2-M4
1
)
719.9 (28
3
/8)
510
(20
1
/8)
53.4
(2
1
/8)
720 (28
3
/8)
4-M5
2
)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1) When using this hole, use a screw which can be inserted into the monitor to a depth of 6 to 16 mm (
1
/4 to
21
/32 inches).
2) When using this hole, use a screw which can be inserted into the monitor to a depth of 46 to 55 mm (1
1
/4 to 2
1
/4 inches).
