Aperture modification frequency for each signal system
An empty frame in the table means that the signal cannot be input or the aperture modification cannot operate for that signal even if it is input.
Signal system Serial digital input Analog input
SDI HD SDI Composite (Y/C) Component (YP
BPR)GBR
575/50I 5 MHz 5 MHz 5 MHz 5 MHz
480/60I 5 MHz 5 MHz 5 MHz 5 MHz
1080/48I 25 MHz 25 MHz 25 MHz
1080/50I 25 MHz 25 MHz 25 MHz
576/50P 25 MHz 25 MHz
480/60P 25 MHz 25 MHz
1035/60I 25 MHz 25 MHz 25 MHz
1080/60I 25 MHz 25 MHz 25 MHz
720/50P 25 MHz 25 MHz 25 MHz
720/60P 25 MHz 25 MHz 25 MHz
