REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
CPD-210GS/210EST
7-2
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
(a)
D009 8-719-900-23 DIODE GL-2AR1
D010 8-719-900-23 DIODE GL-2AR1
D011 8-719-900-23 DIODE GL-2AR1
D012 8-719-900-23 DIODE GL-2AR1
D013 8-719-070-90 DIODE 1N4148
D014 8-719-109-66 ZENER DIODE RD3.3ESB2
D016 8-719-074-25 DIODE RGP10D
D101 8-719-900-23 DIODE GL-2AR1
D102 8-719-900-23 DIODE GL-2AR1
D103 8-719-074-15 DIODE BAV20
D104 8-719-074-15 DIODE BAV20
D105 8-719-074-15 DIODE BAV20
D201 8-719-900-23 DIODE GL-2AR1
D202 8-719-900-23 DIODE GL-2AR1
D203 8-719-074-15 DIODE BAV20
D204 8-719-074-15 DIODE BAV20
D205 8-719-074-15 DIODE BAV20
D301 8-719-900-23 DIODE GL-2AR1
D302 8-719-900-23 DIODE GL-2AR1
D303 8-719-074-15 DIODE BAV20
D304 8-719-074-15 DIODE BAV20
D305 8-719-074-15 DIODE BAV20
<FERRITE BEAD>
FB001 1-412-911-11 FERRITE 2.3UH
FB002 1-412-911-11 FERRITE 2.3UH
FB003 1-412-911-11 FERRITE 2.3UH
FB004 1-412-911-11 FERRITE 2.3UH
FB005 1-412-911-11 FERRITE 2.3UH
FB006 1-412-911-11 FERRITE 2.3UH
FB007 1-412-911-11 FERRITE 2.3UH
FB008 1-412-911-11 FERRITE 2.3UH
FB009 1-412-911-11 FERRITE 2.3UH
FB010 1-412-911-11 FERRITE 2.3UH
<IC>
IC001 8-759-582-06 IC M52743BSP
IC002 IC LM2407T
IC003 8-759-582-07 IC M35045
IC004 8-759-370-08 IC 24LC21T/SN
<JACK>
J001 ¡ 1-251-335-11 SOCKET, PICTURE TUBE
<COIL>
L001 1-469-400-11 INDUCTOR 100UH
L002 1-469-400-11 INDUCTOR 100UH
L101 1-469-398-11 INDUCTOR 0.1UH
L102 1-469-399-11 INDUCTOR 0.68UH
L201 INDUCTOR 0.1UH
L202 1-469-399-11 INDUCTOR 0.68UH
L301 INDUCTOR 0.1UH
L302 1-469-399-11 INDUCTOR 0.68UH
<TRANSISTOR>
Q001 8-729-139-04 TRANSISTOR 2N3904
Q002 8-729-139-04 TRANSISTOR 2N3904
Q003 8-729-139-04 TRANSISTOR 2N3904
Q004 8-729-139-04 TRANSISTOR 2N3904
Q005 8-729-029-86 TRANSISTOR DTC124ESA
Q006 8-729-048-20 TRANSISTOR BF420
Q007 9-910-999-34 TRANSISTOR 2SC945-P
Q008 8-729-139-04 TRANSISTOR 2N3904
Q101 8-729-119-80 TRANSISTOR 2SC2688-LK
Q201 8-729-119-80 TRANSISTOR 2SC2688-LK
Q301 8-729-119-80 TRANSISTOR 2SC2688-LK
<RESISTOR>
R001 1-247-815-91 CARBON 220 5% 1/4W
R002 1-216-025-91 RES,CHIP 100 5% 1/10W
R004 1-216-025-91 RES,CHIP 100 5% 1/10W
R005 1-216-049-91 RES,CHIP 1K 5% 1/10W
R006 1-216-073-00 RES,CHIP 10K 5% 1/10W
R007 1-216-025-91 RES,CHIP 100 5% 1/10W
R008 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R009 1-216-049-91 RES,CHIP 1K 5% 1/10W
R010 1-216-025-91 RES,CHIP 100 5% 1/10W
R011 1-216-037-00 RES,CHIP 330 5% 1/10W
R012 1-216-049-91 RES,CHIP 1K 5% 1/10W
R013 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R014 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R015 1-247-816-11 CARBON 240 5% 1/4W
R016 1-216-041-11 METAL CHIP 470 5% 1/10W
R017 1-216-025-91 RES,CHIP 100 5% 1/10W
R018 1-216-025-91 RES,CHIP 100 5% 1/10W
R019 1-216-025-91 RES,CHIP 100 5% 1/10W
R020 1-247-838-00 CARBON 2K 5% 1/4W
R021 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R022 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R024 1-216-049-91 RES,CHIP 1K 5% 1/10W
R025 1-247-816-11 CARBON 240 5% 1/4W
R026 1-216-042-00 RES,CHIP 510 5% 1/10W
R027 1-216-049-91 RES,CHIP 1K 5% 1/10W
R028 1-216-049-91 RES,CHIP 1K 5% 1/10W
R029 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R030 1-216-073-00 RES,CHIP 10K 5% 1/10W
R031 1-216-094-00 RES,CHIP 75K 5% 1/10W
R032 1-216-109-00 RES,CHIP 330K 5% 1/10W
R033 1-247-872-11 CARBON 51K 5% 1/4W
R034 1-260-192-91 CARBON 51K 5% 1/2W
R035 1-216-017-00 METAL CHIP 47 5% 1/10W
R036 1-216-017-00 METAL CHIP 47 5% 1/10W
R037 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R038 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R039 1-216-058-00 RES,CHIP 2.4K 5% 1/10W
R040 1-240-888-11 METAL 33.2 1% 1/4W
R046 1-216-049-00 RES,CHIP 1K 5% 1/10W
R048 1-215-417-00 METAL 680 1% 1/4W
