REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
CPD-210GS/210EST
7-3
The components identified by mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
(a)(d)
R049 1-216-080-00 RES,CHIP 20K 5% 1/10W
R051 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R101 1-216-022-00 RES,CHIP 75 5% 1/10W
R103 1-216-049-91 RES,CHIP 1K 5% 1/10W
R104 1-216-025-91 RES,CHIP 100 5% 1/10W
R107 1-240-911-11 METAL OXIDE 16K 5% 1W F
R108 1-216-097-91 RES,CHIP 100K 5% 1/10W
R111 1-216-121-91 RES,CHIP 1M 5% 1/10W
R112 1-260-091-11 CARBON 220 5% 1/2W
R113 1-216-013-00 RES,CHIP 33 5% 1/10W
R114 1-260-112-91 CARBON 12K 5% 1/2W
R115 1-215-477-00 METAL 220K 1% 1/4W
R116 1-215-404-00 METAL 200 1% 1/4W
R201 1-216-022-00 RES,CHIP 75 5% 1/10W
R203 1-216-049-91 RES,CHIP 1K 5% 1/10W
R204 1-216-025-91 RES,CHIP 100 5% 1/10W
R207 1-240-911-11 METAL OXIDE 16K 5% 1W F
R208 1-249-449-11 CARBON 100K 5% 1/4W
R211 1-216-121-91 RES,CHIP 1M 5% 1/10W
R212 1-260-091-11 CARBON 220 5% 1/2W
R213 1-216-013-00 RES,CHIP 33 5% 1/10W
R214 1-260-112-91 CARBON 12K 5% 1/2W
R215 1-215-477-00 METAL 220K 1% 1/4W
R216 1-215-404-00 METAL 200 1% 1/4W
R301 1-216-022-00 RES,CHIP 75 5% 1/10W
R303 1-249-417-11 CARBON 1K 5% 1/4W
R304 1-216-025-91 RES,CHIP 100 5% 1/10W
R307 1-240-911-11 METAL OXIDE 16K 5% 1W F
R308 1-249-441-11 CARBON 100K 5% 1/4W
R311 1-216-121-91 RES,CHIP 1M 5% 1/10W
R312 1-260-091-11 CARBON 220 5% 1/2W
R313 1-216-013-00 RES,CHIP 33 5% 1/10W
R314 1-260-112-91 CARBON 12K 5% 1/2W
R315 1-247-887-00 CARBON 220K 5% 1/4W
R316 1-215-404-00 METAL 200 1% 1/4W
<SPARK GAP>
SG001 1-519-422-11 GAP, SPARK
SG101 1-517-499-11 GAP, SPARK
SG201 1-517-499-11 GAP, SPARK
SG301 1-517-499-11 GAP, SPARK
*******************************************************************************
* A-1343-665-A D BOARD, COMPLETE
****************************
1-500-619-11 INDUCTOR (D503)
1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
(R603)
1-533-223-11 HOLDER, FUSE (F601)
* 1-537-738-21 TERMINAL, EARTH
1-785-907-11 PLUG, CONNECTOR 1P
(R530, R583, R614)
* 1-900-801-67 CONNECTOR ASSY
4-045-132-01 HOLDER (A), LED
4-060-176-01 COVER, VOLUME 6 MOLD (RV501)
4-382-854-11 SCREW (M3X10), P, SW (+)
(IC401, IC503, IC907, Q501, Q503, Q504,
Q523, Q602, D508)
7-685-881-09 SCREW +BVTT 4X8 (S)
<CAPACITOR>
C402 1-128-528-11 ELECT 470MF 20% 25V
C403 1-137-393-11 FILM 0.01MF 5% 100V
C404 1-107-914-11 ELECT 1000MF 20% 25V
C405 1-137-378-11 FILM 0.22MF 5% 50V
C406 1-136-298-00 FILM 0.0033MF 5% 100V
C407 1-137-455-11 FILM 0.012MF 5% 100V
C408 1-126-951-11 ELECT 470MF 20% 35V
C409 1-106-343-00 MYLAR 0.001MF 10% 100V
C5E4 1-126-964-11 ELECT 10MF 20% 50V
C5E5 1-104-664-11 ELECT 47MF 20% 16V
C5E6 1-136-165-00 FILM 0.1MF 5% 50V
C5E7 1-136-298-00 FILM 0.0033MF 5% 100V
C5E8 1-137-378-11 FILM 0.22MF 5% 50V
C5E9 1-137-378-11 FILM 0.22MF 5% 50V
C501 1-137-399-11 FILM 0.1MF 5% 100V
C502 1-136-165-00 FILM 0.1MF 5% 50V
C503 1-136-165-00 FILM 0.1MF 5% 50V
C504 1-137-393-11 FILM 0.01MF 5% 100V
C505 1-136-165-00 FILM 0.1MF 5% 50V
C506 1-137-393-11 FILM 0.01MF 5% 100V
C507 1-137-391-11 FILM 0.0047MF 5% 100V
C508 1-102-973-00 CERAMIC 100PF 5% 50V
C509 1-136-298-00 FILM 0.0033MF 5% 100V
C510 1-107-914-11 ELECT 1000MF 20% 25V
C512 1-102-973-00 CERAMIC 100PF 5% 50V
C513 1-102-973-00 CERAMIC 100PF 5% 50V
C515 1-136-205-11 FILM 0.022MF 5% 400V
C516 1-115-349-51 CERAMIC 0.01MF 2KV
C517 1-128-981-11 CERAMIC 220PF 10% 3KV
C518 1-104-331-11 CERAMIC 0.0022MF 10% 1KV
C521 1-107-864-11 FILM 0.0051MF 3% 2.5KV
C522 1-136-539-11 FILM 0.0022MF 3% 2KV
C523 1-128-582-11 ELECT 10MF 20% 100V
C524 1-115-522-11 FILM 1MF 5% 250V
C525 1-127-979-11 MYLAR 0.36MF 5% 400V
C526 1-115-511-11 FILM 0.12MF 5% 250V
C527 1-115-512-11 FILM 0.15MF 5% 250V
