REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
CPD-210GS/210EST
7-4
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
(d)
C528 1-136-165-00 FILM 0.1MF 5% 50V
C529 1-136-165-00 FILM 0.1MF 5% 50V
C530 1-136-165-00 FILM 0.1MF 5% 50V
C531 1-137-395-91 FILM 0.022MF 5% 100V
C532 1-136-298-00 FILM 0.0033MF 5% 100V
C533 1-137-378-11 FILM 0.22MF 5% 50V
C535 1-106-343-00 MYLAR 0.001MF 10% 100V
C536 1-102-112-00 CERAMIC 330PF 10% 50V
C537 1-104-664-11 ELECT 47MF 20% 16V
C538 1-137-455-11 FILM 0.012MF 5% 100V
C539 1-137-350-11 FILM 0.015MF 5% 100V
C540 1-137-464-11 FILM 0.039MF 5% 100V
C541 1-126-934-11 ELECT 220MF 20% 16V
C542 1-137-395-91 FILM 0.022MF 5% 100V
C543 1-102-244-00 CERAMIC 220PF 10% 500V
C545 1-136-165-00 FILM 0.1MF 5% 50V
C546 1-136-165-00 FILM 0.1MF 5% 50V
C547 1-130-495-00 FILM 0.1MF 5% 50V
C548 1-126-934-11 ELECT 220MF 20% 16V
C549 1-126-934-11 ELECT 220MF 20% 16V
C550 1-128-986-11 FILM 0.01MF 5% 250V
C553 1-104-664-11 ELECT 47MF 20% 16V
C554 1-107-667-11 ELECT 2.2MF 20% 160V
C555 1-136-165-00 FILM 0.1MF 5% 50V
C556 1-107-955-11 ELECT 100MF 20% 200V
C560 1-136-165-00 FILM 0.1MF 5% 50V
C570 1-104-331-11 CERAMIC 0.0022MF 10% 1KV
C584 1-109-878-11 CERAMIC 15PF 5% 2KV
C585 1-164-143-11 CERAMIC 0.001MF 10% 1KV
C587 1-127-979-11 MYLAR 0.36MF 5% 400V
C588 1-136-191-11 FILM 0.22MF 5% 250V
C589 1-126-960-11 ELECT 1MF 20% 50V
C590 1-136-165-00 FILM 0.1MF 5% 50V
C591 1-136-165-00 FILM 0.1MF 5% 50V
C592 1-126-964-11 ELECT 10MF 20% 50V
C593 1-137-378-11 FILM 0.22MF 5% 50V
C594 1-117-216-11 CERAMIC 0.0022MF 10% 3KV
C595 1-136-209-11 FILM 0.1MF 5% 400V
C596 1-104-331-11 CERAMIC 0.0022MF 10% 1KV
C597 1-136-298-00 FILM 0.0033MF 5% 100V
C598 1-136-169-00 FILM 0.22MF 5% 50V
C599 1-126-969-11 ELECT 220MF 20% 50V
C601 ¡ 1-104-708-51 FILM 0.47MF 20% 250V
C602 ¡ 1-107-533-51 FILM 1MF 20% 250V
C603 ¡ 1-113-905-91 CERAMIC 220PF 10% 250V
C604 ¡ 1-113-920-91 CERAMIC 0.0022MF 20% 250V
C605 1-113-924-11 CERAMIC 0.0047MF 20% 250V
C606 1-113-707-11 ELECT (BLOCK)220MF 20% 450V
C607 1-126-947-11 ELECT 47MF 20% 35V
C608 1-136-209-11 FILM 0.1MF 5% 400V
C611 1-102-002-00 CERAMIC 680PF 10% 500V
C612 1-137-393-11 FILM 0.01MF 5% 100V
C613 1-102-244-00 CERAMIC 220PF 10% 500V
C614 1-136-165-00 FILM 0.1MF 5% 50V
C615 1-126-933-11 ELECT 100MF 20% 16V
C616 1-136-165-00 FILM 0.1MF 5% 50V
C618 1-126-964-11 ELECT 10MF 20% 50V
C619 1-136-165-00 FILM 0.1MF 5% 50V
C620 1-128-982-11 CERAMIC 330PF 1KV
C622 1-102-121-00 CERAMIC 0.0022MF 10% 50V
C623 1-136-165-00 FILM 0.1MF 5% 50V
C625 1-125-700-11 ELECT (BLOCK)220MF 20% 200V
C626 1-107-955-11 ELECT 100MF 20% 200V
C628 1-107-914-11 ELECT 1000MF 20% 25V
C630 1-128-528-11 ELECT 470MF 20% 25V
C632 1-126-935-11 ELECT 470MF 20% 16V
C633 1-107-914-11 ELECT 1000MF 20% 25V
C634 1-107-884-11 ELECT 1000MF 20% 16V
C635 1-126-926-11 ELECT 1000MF 20% 10V
C636 1-164-143-11 CERAMIC 0.001MF 10% 1KV
C647 1-126-947-11 ELECT 47MF 20% 35V
C648 ¡ 1-113-924-91 CERAMIC 0.0047MF 20% 250V
C649 ¡ 1-113-924-91 CERAMIC 0.0047MF 20% 250V
C651 1-107-914-11 ELECT 1000MF 20% 25V
C901 1-136-165-00 FILM 0.1MF 5% 50V
C903 1-126-961-11 ELECT 2.2MF 20% 50V
C904 1-126-961-11 ELECT 2.2MF 20% 50V
C905 1-126-961-11 ELECT 2.2MF 20% 50V
C906 1-126-961-11 ELECT 2.2MF 20% 50V
C907 1-126-964-11 ELECT 10MF 20% 50V
C908 1-136-165-00 FILM 0.1MF 5% 50V
C910 1-126-964-11 ELECT 10MF 20% 50V
C912 1-102-112-00 CERAMIC 330PF 10% 50V
C913 1-102-973-00 CERAMIC 100PF 5% 50V
C914 1-126-964-11 ELECT 10MF 20% 50V
C915 1-162-815-11 CERAMIC 47PF 5% 500V
C916 1-162-815-11 CERAMIC 47PF 5% 500V
C917 1-126-961-11 ELECT 2.2MF 20% 50V
C923 1-126-961-11 ELECT 2.2MF 20% 50V
C927 1-162-815-11 CERAMIC 47PF 5% 500V
C928 1-162-815-11 CERAMIC 47PF 5% 500V
C929 1-102-973-00 CERAMIC 100PF 5% 50V
C930 1-136-165-00 FILM 0.1MF 5% 50V
C950 1-102-074-00 CERAMIC 0.001MF 10% 50V
C951 1-102-074-00 CERAMIC 0.001MF 10% 50V
<CONNECTOR>
CN501*1-580-798-11 CONNECTOR PIN (DY) 6P
CN504*1-564-513-11 PLUG, CONNECTOR 10P
CN506 1-695-915-11 TAB CONTACT
CN601¡1-251-444-11INLET, AC
CN603*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN901 1-764-334-11 PLUG, CONNECTOR 11P
CN902*1-564-511-11 PLUG, CONNECTOR 8P
<DIODE>
D402 8-719-052-88 DIODE 1N4002
D501 8-719-911-19 DIODE 1SS119-25
D502 8-719-923-03 ZENER DIODE MTZJ-T-73-15A
D503 8-719-200-89 DIODE 31DF2-FA
