CPD-E530 (E) 6
MODE AT PRODUCTION MODE 1 MODE 2
RESOLUTION 640 X 480 1600 X 1200
CLOCK 25.175 MHz 229.500 MHz
— HORIZONTAL —
H-FREQ 31.469 kHz 106.250 kHz
usec usec
H. TOTAL 31.778 9.412
H. BLK 6.356 2.440
H. FP 0.636 0.279
H. SYNC 3.813 0.837
H. BP 1.907 1.325
H. ACTIV 25.422 6.972
— VERTICAL —
V. FREQ (HZ) 59.940 Hz 85.000 Hz
lines lines
V. TOTAL 525 1250
V. BLK 45 50
V. FP 10 1
V. SYNC 23
V. BP 33 46
V. ACTIV 480 1200
— SYNC —
INT(G) NO NO
EXT (H/V) /POLARITY YES N/N YES P/P
EXT (CS) /POLARITY NO NO
INT/NON INT NON INT NON INT
TIMING SPECIFICATION
2001.11.15 VER.
