KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
— 20 —
SERVICE DATA LISTS
Device Name
Device Reference
Number
Slave Address Comment
# 1 3D-COMB mPD64082 IC3501 / BC-board B8h (W) & B9h (R) W&R: Write & Read
# 2-1 CXA2103-1 (Main) IC3048 (Main) / B-board 9Ah
# 2-2 CXA2103-2 (Sub) IC3110 (Sub) / B-board 9Eh
# 3-1 CXA2150P-1
# 3-2 CXA2150P-2
# 3-3 CXA2150P-3
# 3-4 CXA2150P-4
# 4-1 CXA2150D-1
# 4-2 CXA2150D-2
# 4-3 CXA2150D-3
# 5 CXA2151 CXA2151Q IC3001 / B-board 84h
# 6 D-CONV CXA8070P IC5513 / D-board DEh
# 7 CXA2026 CXA2026AS IC5511 / D-board 8Eh
# 8 AP BH3868AFS IC7001 / A-board 82h
# 9 TRUS NJM2180M IC4101 / S-board 2Eh Controlled through CXA1315M ( IC4103 / S-board / 48h )
# 10 MID1 CXD9509AQ IC3408 / B-board 2Eh Controlled through MID-XA Micro ( IC3090 / B-board / 64h )
# 11 MID2 CXD9509AQ IC3408 / B-board 2Eh Controlled through MID-XA Micro ( IC3090 / B-board / 64h )
# 12 MID3 CXD9509AQ IC3408 / B-board 2Eh Controlled through MID-XA Micro ( IC3090 / B-board / 64h )
# 13 MID5 CXD9509AQ IC3408 / B-board 2Eh Controlled through MID-XA Micro ( IC3090 / B-board / 64h )
# 14 OSD M306V2ME-153FP IC701 / A-board 60h DX1A-2001 S
y
stem Micro
{
V1.0
}
mPD64082 IC3501 / BC-board B8h (W) & B9h (R)
CXA2103Q IC3048 (Main) / B-board 9Ah
CXA2150Q IC201 / A-board 86h
# 16 ID1 CXD2085M IC3603 / B-board 40h
IC3602 (Main) / B-board 68h (Main)
IC3601 (Sub) / B-board 6Ch (Sub)
# 18 OP M306V2ME-153FP IC701 / A-board 60h DX1A-2001 S
y
stem Micro
{
V1.0
}
# 19 ID M306V2ME-153FP IC701 / A-board 60h DX1A-2001 S
y
stem Micro
{
V1.0
}
DX1A-2001 System Micro &
Notes for Services
DX1A-2001 MID-XA Micro
M306V2ME-153FP (MASK), Software Version 1.0, IC701/A-board (Slave Adress: 60h)
The system micro name, software&patch versions, and the status of NVM devices are displayed only when in the service catergory
DX1A-2001 CCD&Vchip Micro
s
MB94918RPF-G-137-BND (MASK), Software Version 12/08/00, IC3090/B-board (Slave Address: 64h)
CXP85840A-039Q (MASK), Software Version 2.14, IC3602/B-board (Main/Slave Address: 68h) & IC3601/B-board (Sub/Slave Address: 6
Note:
* This service list is used for DX1A-2001 ONLY. Some service data is the same in DX1A-2001 & 2000, as noted in the data sheets.
# 17
CCD&VCHIP
CCD&Vchip Micro (V2.14)
DX1A-2001* Service List ------ Contents & Notes
Category Number & Name
# 15
CXA2103Q
CXA2150AQ 86h
CXP85840A-039Q
SNNR
CXA2150AQ
IC201 / A-board
IC201 / A-board 86h
