— 95 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
SECTION 7: ELECTRICAL PARTS LIST
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonß ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF.NO. PART NO. DESCRIPTION VALUES
The components in this manual identiÞ ed by the following
symbol:
indicate parts that have been carefully factory-
selected to satisfy regulations regarding X-ray radiation for
each set.
Should replacement be required for one of these
components, replace only with the value originally used.
NOTE: The components identiÞ ed by shading
and
!
mark are critical for safety. Replace only
with part number speciÞ ed.
NOTE: Les composants identiÞ es per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero speciÞ e.
When ordering parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION VALUES
BC
C3531 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3532 1-126-964-11 ELECT 10µF 20% 50V
C3533 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C3534 1-126-960-11 ELECT 1µF 20% 50V
C3535 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C3536 1-126-960-11 ELECT 1µF 20% 50V
C3537 1-126-964-11 ELECT 10µF 20% 50V
C3538 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C3539 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C3541 1-163-106-00 CERAMIC CHIP 36pF 5% 50V
C3542 1-126-964-11 ELECT 10µF 20% 50V
C3543 1-164-505-11 CERAMIC CHIP 2.2µF 16V
C3546 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C3547 1-126-934-11 ELECT 220µF 20% 10V
C3548 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3549 1-104-660-91 ELECT 47µF 20% 16V
C3550 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3551 1-104-660-91 ELECT 47µF 20% 16V
C3552 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3553 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3554 1-104-660-91 ELECT 47µF 20% 16V
C3555 1-126-934-11 ELECT 220µF 20% 10V
C3556 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C3557 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3558 1-104-660-91 ELECT 47µF 20% 16V
C3559 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3560 1-104-660-91 ELECT 47µF 20% 16V
C3561 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3562 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3563 1-104-660-91 ELECT 47µF 20% 16V
C3564 1-104-660-91 ELECT 47µF 20% 16V
C3565 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3566 1-163-031-91 CERAMIC CHIP 0.01µF 50V
* A-1136-117-A BC BOARD, COMPLETE
CAPACITOR
C3500 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3501 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C3502 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3504 1-163-102-00 CERAMIC CHIP 24pF 5% 50V
C3505 1-163-102-00 CERAMIC CHIP 24pF 5% 50V
C3506 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3507 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3509 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C3510 1-163-131-00 CERAMIC CHIP 390pF 5% 50V
C3511 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C3512 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3513 1-216-295-91 SHORT
C3514 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3515 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3516 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3517 1-126-924-11 ELECT 330µF 20% 6.3V
C3518 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C3519 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3520 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3521 1-163-237-11 CERAMIC CHIP 27pF 5% 50V
C3522 1-104-660-91 ELECT 47µF 20% 16V
C3523 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3524 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3525 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C3526 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3527 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3528 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3529 1-165-319-11 CERAMIC CHIP 0.1µF 50V
C3530 1-104-660-91 ELECT 47µF 20% 16V
BC
