Sony TRINITRON KV-32HS20 - Page 96

REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES
— 96 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
CONNECTOR
* CN3500 1-691-632-21 CONNECTOR, BOARD TO BOARD 15P
FERRITE BEAD
FB3500 1-414-234-22 FERRITE 0µH
FB3501 1-414-234-22 FERRITE 0µH
FB3502 1-414-234-22 FERRITE 0µH
FB3503 1-414-234-22 FERRITE 0µH
FB3504 1-414-234-22 FERRITE 0µH
FB3505 1-414-234-22 FERRITE 0µH
FB3506 1-414-234-22 FERRITE 0µH
FB3507 1-414-234-22 FERRITE 0µH
FB3508 1-414-234-22 FERRITE 0µH
FB3509 1-414-234-22 FERRITE 0µH
FILTER
FL3500 1-239-848-21 FILTER, LOW PASS
FL3501 1-239-848-21 FILTER, LOW PASS
FL3502 1-239-848-21 FILTER, LOW PASS
FL3503 1-239-848-21 FILTER, LOW PASS
FL3504 1-233-512-21 FERRITE 37µH
FL3505 1-233-512-21 FERRITE 37µH
FL3506 1-233-512-21 FERRITE 37µH
IC
IC3500 8-759-568-27 IC UPD424210LE-60-E2
IC3501 8-759-594-44 IC UPD64082GF-3BA
IC3502 8-759-583-47 IC UPC2933T-E1
COIL
L3500 1-414-265-21 INDUCTOR 4.7µH
L3501 1-412-058-11 INDUCTOR 10µH
L3502 1-412-058-11 INDUCTOR 10µH
L3503 1-412-058-11 INDUCTOR 10µH
L3504 1-412-058-11 INDUCTOR 10µH
L3505 1-412-058-11 INDUCTOR 10µH
TRANSISTOR
Q3500 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3501 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3502 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3503 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3504 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3505 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3506 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3508 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3509 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3510 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3511 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3512 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3513 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3514 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3515 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3516 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3517 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
RESISTOR
R3503 1-216-017-91 RES-CHIP 47 5% 1/10W
R3504 1-216-295-91 SHORT
R3505 1-216-295-91 SHORT
R3506 1-216-295-91 SHORT
R3507 1-216-295-91 SHORT
R3508 1-216-295-91 SHORT
R3509 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3510 1-216-041-00 RES-CHIP 470 5% 1/10W
R3511 1-216-041-00 RES-CHIP 470 5% 1/10W
R3512 1-216-295-91 SHORT
R3514 1-216-025-11 RES-CHIP 100 5% 1/10W
R3515 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R3516 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R3517 1-216-025-11 RES-CHIP 100 5% 1/10W
R3518 1-216-025-11 RES-CHIP 100 5% 1/10W
R3519 1-216-295-91 SHORT
R3520 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R3521 1-216-041-00 RES-CHIP 470 5% 1/10W
R3522 1-216-041-00 RES-CHIP 470 5% 1/10W
R3523 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3524 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3525 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3526 1-216-105-91 RES-CHIP 220K 5% 1/10W
R3527 1-216-033-00 RES-CHIP 220 5% 1/10W
R3528 1-208-776-11 METAL CHIP 560 0.50% 1/10W
R3529 1-208-772-11 METAL CHIP 390 0.50% 1/10W
R3530 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R3531 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3532 1-216-025-11 RES-CHIP 100 5% 1/10W
R3534 1-216-049-11 RES-CHIP 1K 5% 1/10W
