KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
D BOARD TRANSISTOR
VOLTAGE LIST (1 OF 3)
D BOARD IC VOLTAGE LIST (1 OF 3)
11 0.0 3 2.5
pin volt 12 4.6 4 11.8
1 2.5 13 N/C 5 GND
2 1.8 14 163.6
3 2.2 15 153.5 pin volt
4 2.5 16 157.6 1 134.9
5 GND 17 N/C 2 15.7
6 0.0 18 1.7 3 GND
7 4.0
8 17.2 pin volt
9 GND 1 134.0
10 10.4 2 N/C
IC6505
IC6503
IC6501
All voltages are in V.
BCE
Q6503 0.0 2.5 0.0
Q6520 131.0 0.0 132.0
Q6521 0.0 2.1 GND
Q6522 15.7 GND 15.7
Q6524 2.1 0.4 4.9
Q6526 5.9 0.0 5.9
Q6527 0.6 0.0 0.0
Q6528 0.6 0.0 0.0
Q6529 0.0 5.9 0.0
Q6530 4.7 0.0 4.7
Q6531 0.6 0.0 GND
Q6532 0.0 4.7 GND
DGS
Q6506 4.7 149.2 0.0
Q6507 154.4 303.3 150.0
All voltages are in V.
