– 2 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
Power requirements 220-240 V AC, 50/60 Hz KV-AR34M36/AR34M60/
AR34M64 (THAILAND)
110-240 V AC, 50/60 Hz KV-AR34M64 (INDIA)/
AR34M66/AR34M94
Power consumption (W) Indicated on the rear of the TV
Television system B/G, I, D/K, M
Color system PAL, PAL 60, SECAM, NTSC3.58, NTSC4.43
Stereo/Bilingual System NICAM Stereo/ Bilingual B/G, I;A2 Stereo/ Bilingual B/G
Teletext language English, Arabic, French KV-AR34M36/AR34M66 Only
Channel coverage
B/G VHF: E2 to E12 / UHF: E21 to E69
CATV: S01 to S03, S1 to S41
I UHF: B21 to B68 / CATV: S01 to S03, S1 to S41
D/K VHF: C1 to C12, R1 to R12 /
UHF: C13 to C57, R21 to R60 /
CATV: S01 to S03, S1 to S41, Z1 to Z39
M VHF: A2 to A13 / UHF: A14 to A79
CATV: A-8 to A-2, A to W+4, W+6 to W+84
(Antenna) 75-ohm external terminal
Audio output (Speaker) 8W + 8W
Number of terminal
DVideo Input: 4* Output: 1 * Three input lines available Phono jacks; 1 Vp-p, 75 ohms
≥ Audio Input: 4* Output: 1 * Three input lines available Phono jacks; 500 mVrms
(S Video) Input : 2 Y: 1 Vp-p, 75 ohms
unbalanced, sync negative
C: 0.286 Vp-p, 75 ohms
(Component Input : 1 Phono jacks:
Video) Y: 1 Vp-p, 75 ohms
sync negative
C
B: 0.7 Vp-p, 75 ohms
C
R: 0.7 Vp-p, 75 ohms
Audio: 500mVrms
2 (Headphone) Output: 1 Stereo minijack
Picture tube 34
Tube size (cm) 86 Measured diagonally
Screen size (cm) 80 Measured diagonally
Dimension (w/h/d,mm) 896 × 686 × 569
Mass (kg) 78
Design and specifications are subject to change without notice.
SPECIFICATIONS
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK ! ON
THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE
PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND
THE ANODE CAP TO THE METAL CHASSIS, CRT SHIELD, OR
CARBON PAINTED ON THE CRT, AFTER REMOVING THE
ANODE.
