Sony TRINITRON KV-AR34M3 - Circuit Board Location

– 48 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
5-2. CIRCUIT BOARDS LOCATION
VM1 Board
H1 Board
F Board
C6 Board
H2 Board
D2 Board
P5 Board
B8 Board
J Board
V1 Board
(KV-AR34M36/AR34M66)
A Board
DH Board
(Except KV-AR34M36)
(KV-AR34M60 ONLY)
(EXCEPT KV-AR34M60)
C6 Board
H2 Board
A Board
V1 Board
(not used for this model)
J Board
B10 Board
B1 Board
F Board
H1 Board
VM1 Board
Speaker
(5cm)
Speaker
(15 x 6.5cm)
D2 Board
DH Board
