Sony TRINITRON KV-AR34M3 - Picture Distortion Adjustment

– 43 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
4-9. PICTURE DISTORTION ADJUSTMENT (1)
Item Number 00 – 0B
PICTURE DISTORTION ADJUSTMENT (2)
GEO 1 HSZ ( H SIZE)
GEO 3 TLT (TRAPEZIUM)
GEO 0A
GEO 0B
GEO 5
GEO 0 HPS (H POSITION)
GEO 9
UPN (UPPER CORNER PIN)
LPN (LOWER CORNER PIN)
AGL (AFC. ANGLE)
GEO 8
GEO 2 PAP (PIN AMP)
GEO 4 VPS (V POSITION)
GEO 7
GEO 6
VSZ (V SIZE)
BOW (AFC. BOW)
VLN (V LINEARITY)
SCO (VERTICAL S-Correction)
H-TRAPEZOID (DAC 4 HTR)
