Sony TRINITRON KV-AR34M3 - Page 70

– 83 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
41 5.1
840mVp-p
PA L
13
720mVp-p
13
NTSC3.58
42 0
43 5.0
44 4.8
45 (5.3)[5.5]
46 5.0
47 8.6
48 0.2
49 4.4
50 0
51 (2.6)[2.3]
52 (2.3)[1.8]
IC302 1 1.5
20
3 1.4
40
5 1.6
60
7 4.7
8 0.6
90
10 1.0
11 4.9
12 4.8
13 0
14 1.0
15 0
16 0.8
IC601 1 2.1
20
3 185.0
4 17.0
50
IC603 I 12.7
G0
O 8.8
IC604 I 8.2
G0
O 4.9
Q001 B 4.9
C0
E 0.2
Q002 B 0
C 4.9
E0
Q101 B 3.5
C 8.7
E 2.9
Q301 B 12.6
C0
E 12.5
Q302 B 1.5
C 8.0
E 0.8
Q303 B 8.0
C 1.4
E 8.6
Q304 B 3.5
C0
E 4.2
Q305 B 8.0
C 1.6
E 8.6
Q306 B 1.4
C 8.6
E 0.8
Q307 B 4.3
C 8.6
E 3.5
Q308 B 3.5
C 0.4
E 0.8
Q309 B 4.7
C0
E0
Q310 B 0.2
C 4.9
E0
Q311 B 0
C 8.8
E0
Q312 B 4.4
C0
E 5.6
Q313 B 0
C 12.5
E0
Q314 B 0.4
C0
E 1.0
Q315 B 0
C 3.5
E0
Q316 B 4.0
C0
E 4.7
Q317 B 4.0
C0
E 4.7
Q501 B 3.4
C0
E 4.0
Q502 B 4.3
C 1.5
E 4.0
Q503 B 0
C 3.3
E0
Q505 S 0
G (6.3)[6.1]
D 156
Q506 B 0.6
C 92.1
156Vp-p
PA L
14
148Vp-p
14
NTSC3.58
E0
Q507 B 12.5
C 0.3
E 13.0
Q509 B 0.6
C0
E0
Q511 B 1.1
C0
366Vp-p
PA L
15
322Vp-p
15
NTSC3.58
E 1.2
Q600 B 0
C 12.7
E0
Q601 B 0.6
C 0.3
E 0.6
Q602 B 0
C 17.0
E0
Q603 B 17.0
C (3.2)[3.5]
E 17.0
Q604 B 134.2
C0
E 134.6
Q605 S 0.6
G0
D 266.0
Q606 B 0
C 0.2
E 0.6
Q607 B (1.8)[1.5]
C 1.3
E (1.5)[1.1]
Q608 B 0
C 0.8
E0
2.36Vp-p
PA L
16
2.16Vp-p
16
NTSC3.58
2.36Vp-p
PA L
16
2.16Vp-p
16
NTSC3.58
