Sony TRINITRON KV-AR34M3 - Page 93

– 113 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
REF. NO. PART NO. DESCRIPTION REMARK
151 X-4040-514-1 BEZNET ASSY 152-154, 172, 173
(EXCEPT KV-AR34M60)
X-4040-576-1 BEZNET ASSY (KV-AR34M60 ONLY)
152 4-036-405-11 SPRING, COMPRESSION
153 4-086-448-01 BUTTON, POWER (KV-AR34M36/
AR34M64(THAILAND)/AR34M66)
4-087-797-01 BUTTON, POWER (KV-AR34M60)
4-087-769-01 BUTTON POWER (KV-AR34M64(INDIA)/
AR34M94)
154 * 4-086-707-01 GUIDE, LIGHT (EXCEPT KV-AR34M60)
* 4-087-797-01 GUIDE, LIGHT (KV-AR34M60 ONLY)
155 ! 8-735-076-05 PICTURE TUBE (A80LPD90X)
(KV-AR34M36/AR34M94)
! 8-735-077-05 PICTURE TUBE (A80LPD90X)
(KV-AR34M60/AR34M64/AR34M66/AR34M94)
156 * 3-704-372-11 HOLDER, HV CABLE
(EXCEPT KV-AR34M64(INDIA)/AR34M94)
* 3-704-372-41 HOLDER, HV CABLE
(KV-AR34M64/AR34M94)
157 4-046-600-11 SPACER, DY (KV-AR34M36/AR34M66/
AR34M64(INDIA)/AR34M94)
4-064-818-01 SPACER, DY
(KV-AR34M60/AR34M64(THAILAND))
158 X-4387-214-3 PERMALOY ASSY, CORRECTION
(KV-AR34M36/AR34M66/AR34M64(INDIA)/
AR34M94)
4-051-734-42 PIECE B(120) CONV, CORRECT
(KV-AR34M64(THAILAND)/AR34M60)
159 ! 8-451-499-31 DEFLECTION YOKE (Y34RSA-Y)
160 * A-1401-285-A C6 BOARD, MOUNTED (VAR)
(KV-AR34M36/AR34M66)
* A-1401-348-A C6 BOARD, MOUNTED (KV-AR34M60)
* A-1401-324-A C6 BOARD, MOUNTED
(KV-AR34M64(THAILAND))
* A-1401-477-A C6 BOARD, MOUNTED (VAR)
(KV-AR34M64(INDIA)/AR34M94)
161 ! 1-419-293-11 COIL, DEGAUSSING (KV-AR34M36/AR34M66)
! 1-419-293-21 COIL, DEGAUSSING
(KV-AR34M64(THAILAND)/AR34M60)
! 1-419-293-21 COIL, DEGAUSSING
(KV-AR34M64/AR34M94)
REF. NO. PART NO. DESCRIPTION REMARK
162 * 4-074-512-21 CUSHION S, DGC (KV-AR34M36/AR34M66)
* 4-074-512-31 CUSHION S, DGC (KV-AR34M64(THAILAND)/
AR34M60)
163 4-061-369-01 HOLDER, DEGAUSSE COIL
164 1-452-896-61 COIL, NA ROTATION (RT200)
(KV-AR34M36/AR34M66)
1-452-896-81 COIL, NA ROTATION
(KV-AR34M60/AR34M64(THAILAND))
1-452-896-61 COIL ROTATION (RT200)
(KV-AR34M64(INDIA)/AR34M66/AR34M94)
165 * A-1401-238-A VM1 BOARD, MOUNTED
(KV-AR34M36/AR34M66)
* A-1401-349-A VM1 BOARD, MOUNTED (KV-AR34M60)
* A-1401-327-A VM1 BOARD, MOUNTED
(KV-AR34M64(THAILAND)
* A-1401-479-A VM1 BOARD, MOUNTED
(KV-AR34M64(INDIA)/AR34M94)
166 4-078-766-01 SPRING, TENSION (KV-AR34M36)
4-078-766-11 SPRING, EXTENSION (KV-AR34M64(INDIA)/
AR34M66/AR34M94)
167 1-452-032-00 MAGNET DISC
168 1-452-094-00 CIRCULAR DISC MAGNET
169 4-077-228-02 PIECE TLH CONVERGENCE
170 4-067-455-01 BAND, DGC
171 8-453-007-31 NA324-M38
172 4-087-488-01 DOOR (KV-AR34M60/AR34M64/AR34M94)
4-088-697-01 DOOR (KV-AR34M66)
4-089-041-01 CONTROL DOOR (EXCEPT KV-AR34M60)
173 4-087-491-01 SPRING (DOOR)
174 4-387-204-01 NUT, SPECIAL, CRT
175 4-069-493-02 CLIP DGC
176 1-416-871-11 COIL LANDING CORRECTION
(KV-AR34M60(THAILAND)/AR34M64(INDIA)/
AR34M94/AR34M66)
1-419-295-11 COIL LANDING CORRECTION
(KV-AR34M64(THAILAND))
177 * 4-074-513-21 CUSHION (L) DGC
(KV-AR34M36/AR34M64(INDIA)/AR34M66/
AR34M94)
178 X-4040-711-1 REAR COVER ASSY
(EXCEPT KV-AR34M64(INDIA)/AR34M94)
179 4-087-487-01 COVER, REAR
(KV-AR34M64(INDIA)/AR34M94)
