– 32 –
KV-HS29M61/M90/M91, HS34M61/M90/M91, HS38M61/M90/M91
RM-997
Category Item Function Standard Data Device Name
No. Name Field Freq NR0, NTSC NR0, others NR1, NTSC NR1, others NR2, NTSC NR2, others NR3, NTSC NR3, others (Slave Address)
Common 50 60
3NR 00 WHC PLL Divider setting(PAL=47, NTSC=44) 2F 2C TC90A90F(14H)
01 NIQ U/V input polarity 00
02 CLW A/D Clamp Pulse width 1E 1E
03 CLP A/D Clamp Pulse Phase 50 50
04 YBW Y H Blanking width 8A 8A
05 YBL Y Blanking level adjustment 00
06 YBO Internal Y H Blanking ON/OFF 00
07 MUT Signal Output Muting 00
08 YBS Y H Blanking start point 28 28
09 CBW U/V H Blanking width 8A 8A
0A CBS U/V H Blanking start point 28 28
0B CBO Internal U/V H Blanking ON/OFF 00
0C VBL V H Blanking level adjustment 00
0D UBL U H Blanking level adjustment 00
0E CDL U/V output delay 00 00
0F YDL Y output delay 00 00
10 PVI VD input polarity 00
11 PHI HD input polarity 00
12 HDW HD pulse width 10
13 PVO VD output polarity 00
14 PHO HD output polarity 00
15 HST HD out pulse start position 36
16 VDL VD out Pulse start position 00
17 VDW VD out Pulse width 03
18 NDE Noise detection point 00
19 NVP Noise detect line 02
1A NDS Noise detect sencitivity 03
1B HOF H Reference pulse ON/OFF (ON=0) 01
1C NDW Noise detect gate width 09
1D UOS U Offset level 02
1E POT Output Port 0/1 Control 00 01
1F UVF UV Frag polarity 00
20 APC AP Clock polarity 01
21 DAP DAC power save (ON=1) 00
22 YLV Y NR level 00 00 08 08 0C 0C 0E 0E
23 YST Y Standard detection off/on 00
24 YNT Y NTSC Standard detection 01
25 YPL Y PAL Standard detection 01
26 YMV Y Moving detection filter (ON=0) 00
27 YCR Y Moving detection Coring level 00 00 00 00 07 07 0A 0A
28 VOS V Offset level 01
29 YMG Y Moving detection gain 00 00 00 00 00 00 00 00
2A YEG Y Moving detect on (ON=1) 01
2B YEL Y edge moving detection sensitivity 03 03 04 04 03 03 03 03
2C YLM Y NR Feed back limit level 00 00 03 03 04 04 08 08
2D CLV C NR level 00 00 08 08 09 09 0B 0B
2E CNT Relate C NR to YSTDN 01
2F CPL Relate C NR to YSTDP 01
30 CMG C Moving detection gain 00 00 00 00 00 00 00 00
31 CCR C Moving detection level 00 00 00 00 06 06 0C 0C
32 CLM C NR Feed back limit level 00 00 04 04 05 05 05 05
33 NVS NR Vertical start line 14 14
34 NHS NR Horizontal start position 10 10
35 NVE NR Vertical end line (offset:+100d) D2 A0
36 NHE NR Horizontal end position 78 78
37 YNG Y Coring gain 01 01
38 COR Coring/through (Coring=0) 00 00
39 LPF LPF on/off (on=0) 00
3A YLT Y Coring limit level 00 00
3B YNC Y Coring offset level 00 00 08 08 0C 0C 0E 0E
3C YCO Y Coring off (on=1) 01 01
To Next Page
