4
House Current
Connect the supplied AC power cord to the AC IN socket
and to a wall outlet.
To connect an AC power cord securely with AC plug holders
When the AC power cord is plugged into the AC IN socket,
the battery pack (if installed ) or the AC power adaptor (if
connected) is automatically disconnected.
123
1 Remove the AC IN socket screws and then use them to attach AC plug holder A (supplied) to
the AC IN socket.
2 Plug the power cord to the AC IN socket. Then, attach the supplied AC plug holder B on
top of the AC power cord.
3 Slide AC plug holder B over the cord until it connects with AC plug holder A.
To remove the AC power cord
Pull out AC power holder B by squeezing the left and right sides.
Rechargeable Battery
Power Sources
To remove the battery pack, press the EJECT button
upwards.
For charging, use the BC-1WA battery charger (not
supplied) for the NP-1A or the BC-1WB for the NP-1B.
Note
Make sure that the AC power cord and the AC power
adaptor are disconnected from the monitor. Otherwise, the
monitor cannot operate on the battery pack.
To Next Page
