Specifications
Video signal
Color system NTSC3.58, PAL, SECAM, NTSC4.43
Resolution 250 TV lines
Frequency response 6.0 MHz (–3.0 dB) at all inputs
Synchronization AFC time constant 1.0 msec.
Picture performance
Normal scan 6% over scan of CRT effective
screen area
Underscan 3% underscan of CRT effective
screen area
H. linearity Less than 7.0% (typical)
V. linearity Less than 7.0% (typical)
Convergence Central area: 0.50 mm (typical)
Peripheral area: 0.60 mm (typical)
Raster size stability H: 1.0%, V: 1.5%
High voltage regulation
3.0%
Color temperature D65 (PVM-5041Q/6041QM)
D93 (PVM-6041Q)
Inputs and Outputs
Inputs VIDEO IN: BNC connector
1 Vp-p ±6 dB, sync negative
AUDIO IN: phono jack, –5 dBs, less
than 47 kohms
R/R-Y, G/Y, B/B-Y: BNC connector
R, G, B channels: 0.7 Vp-p, ±6 dB
Sync on green: 0.3 Vp-p,
negative,75 ohms terminated
R-Y, Y, B-Y channels:
PVM-5041Q: 0.7 Vp-p, ±6 dB
(standard color bar signal of
75% chrominance)
PVM-6041QM: 0.7 Vp-p, ±6 dB
(standard color bar signal of
100% chrominance)
EXT SYNC IN: BNC connector
Composite sync 4 Vp-p, ±6 dB,
negative
Loop-through outputs
VIDEO OUT: BNC connector,
75 ohms terminated
AUDIO OUT: phono jack
Remote input REMOTE: 8-pin mini DIN
connector (See the pin assign
ment on the right side of this
page)
Audio Output level 0.5 W
General
Power consumption PVM-5041Q:
42 W max at AC operation
40 W at DC operation
PVM-6041QM:
40 W at AC operation
40 W at DC operation
Power requirements PVM-5041Q:
120 V AC, 50/60 Hz
PVM-6041QM:
100 – 240 V AC, 50/60 Hz
12 V DC, with the Sony (NP-1A/1B)
battery pack (not supplied) or
AC-500/500CE AC power adaptor
(not supplied)
Peak inrush current (PVM-6041QM)
Hot switching inrush current, measured in accordance
with European standard EN55103-1:
58A (230V)
Operating temperature range
0 – 35°C
Storage temperature range
–10 – +40°C
Humidity 0 – 90%
Dimensions Approx. 146 × 173 × 352.5 mm (w/h/
d) (5
3
/4 × 6
7
/8 × 14 inches)
not incl. projecting parts and controls
Weight Approx. 5.5 kg (12 lb 2 oz)
not incl. battery packs
Accessory supplied AC power cord (1)
Cable with an 8-pin connector
AC Plug holders (1 set)
Pin Assignment
REMOTE connector (8-pin mini DIN)
Pin No.
1
2
3
4
5
6
7
8
Signal
Blue only
H/V delay
GND
INT/EXT SYNC
–
Underscan/normal scan
RGB/Y, R-Y, B-Y
RGB/LINE
For remote control, connect the pin of the desired function
to pin 3 (GND).
Design and specifications are subject to change without
notice.
