– 61 –
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-BM142M70
RM-W101
<PHOTO COUPLER>
PH600 ! 6-600-187-11 PHOTO COUPLER PC123Y22FZ0F
<IC LINK>
PS602 ! 1-533-597-42 IC LINK 5A 90V
PS603 ! 1-533-597-42 IC LINK 5A 90V
PS604 1-533-597-41 IC LINK 5A 90V
PS605 ! 1-533-597-42 IC LINK 5A 90V
PS2601 ! 1-533-597-42 IC LINK 5A 90V
<TRANSISTOR>
Q001 8-729-421-22 TRANSISTOR UN2211
Q006 8-729-424-67 TRANSISTOR UN2216
Q007 8-729-424-67 TRANSISTOR UN2216
Q008 8-729-010-25 TRANSISTOR MSD601-RT1
Q013 8-729-010-25 TRANSISTOR MSD601-RT1
Q016 8-729-421-22 TRANSISTOR UN2211
Q100 8-729-010-25 TRANSISTOR MSD601-RT1
Q102 8-729-022-54 TRANSISTOR 2SC3779C,D-AA
Q103 8-729-424-67 TRANSISTOR UN2216
Q104 8-729-424-67 TRANSISTOR UN2216
Q111 8-729-010-25 TRANSISTOR MSD601-RT1
Q200 8-729-421-22 TRANSISTOR UN2211
Q201 8-729-010-05 TRANSISTOR MSB709-RT1
Q202 8-729-010-05 TRANSISTOR MSB709-RT1
Q206 8-729-421-22 TRANSISTOR UN2211
Q601 8-729-010-25 TRANSISTOR MSD601-RT1
Q605 6-550-572-01 TRANSISTOR FN155
Q606 8-729-010-25 TRANSISTOR MSD601-RT1
Q608 8-729-010-25 TRANSISTOR MSD601-RT1
Q609 8-729-010-25 TRANSISTOR MSD601-RT1
Q803 8-729-140-50 TRANSISTOR 2SC3209LK
Q804 8-729-200-17 TRANSISTOR 2SA1091-O
Q805 6-550-410-01 TRANSISTOR 2SC5885
Q806 8-729-010-25 TRANSISTOR MSD601-RT1
Q807 8-729-010-05 TRANSISTOR MSB709-RT1
Q808 8-729-053-33 TRANSISTOR IRF614-037
Q814 8-729-010-25 TRANSISTOR MSD601-RT1
Q900 8-729-010-05 TRANSISTOR MSB709-RT1
Q901 8-729-424-67 TRANSISTOR UN2216
Q910 8-729-010-25 TRANSISTOR MSD601-RT1
Q911 8-729-010-25 TRANSISTOR MSD601-RT1
Q912 8-729-421-22 TRANSISTOR UN2211
Q8009 6-550-362-01 TRANSISTOR KTA1279
Q8010 8-729-140-50 TRANSISTOR 2SC3209LK
<RESISTOR>
R001 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R002 1-216-809-11 METAL CHIP 100 5% 1/10W
R003 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R004 1-216-809-11 METAL CHIP 100 5% 1/10W
R010 1-216-833-11 METAL CHIP 10K 5% 1/10W
R011 1-216-821-11 METAL CHIP 1K 5% 1/10W
R012 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R014 1-216-809-11 METAL CHIP 100 5% 1/10W
R015 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R018 1-216-809-11 METAL CHIP 100 5% 1/10W
R020 1-216-809-11 METAL CHIP 100 5% 1/10W
R021 1-216-295-91 SHORT CHIP 0
R023 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R024 1-216-809-11 METAL CHIP 100 5% 1/10W
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-216-809-11 METAL CHIP 100 5% 1/10W
R029 1-216-809-11 METAL CHIP 100 5% 1/10W
R030 1-216-809-11 METAL CHIP 100 5% 1/10W
R038 1-216-809-11 METAL CHIP 100 5% 1/10W
R039 1-216-809-11 METAL CHIP 100 5% 1/10W
R041 1-216-809-11 METAL CHIP 100 5% 1/10W
R042 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R044 1-216-834-11 METAL CHIP 12K 5% 1/10W
R045 1-216-809-11 METAL CHIP 100 5% 1/10W
R046 1-216-809-11 METAL CHIP 100 5% 1/10W
R048 1-216-809-11 METAL CHIP 100 5% 1/10W
R051 1-218-885-11 METAL CHIP 39K 0.50% 1/10W
R056 1-216-809-11 METAL CHIP 100 5% 1/10W
R058 1-216-809-11 METAL CHIP 100 5% 1/10W
R060 1-216-809-11 METAL CHIP 100 5% 1/10W
R061 1-216-819-11 METAL CHIP 680 5% 1/10W
R087 1-216-813-11 METAL CHIP 220 5% 1/10W
R088 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R096 1-216-813-11 METAL CHIP 220 5% 1/10W
R097 1-216-813-11 METAL CHIP 220 5% 1/10W
R098 1-216-813-11 METAL CHIP 220 5% 1/10W
R099 1-216-813-11 METAL CHIP 220 5% 1/10W
R100 1-216-821-11 METAL CHIP 1K 5% 1/10W
R103 1-211-981-11 METAL CHIP 33 0.50% 1/10W
R106 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R107 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R108 1-216-821-11 METAL CHIP 1K 5% 1/10W
R109 1-216-019-00 RES-CHIP 56 5% 1/10W
R110 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-216-833-11 METAL CHIP 10K 5% 1/10W
R112 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R113 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R114 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R115 1-216-809-11 METAL CHIP 100 5% 1/10W
R116 1-216-809-11 METAL CHIP 100 5% 1/10W
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R119 1-211-981-11 METAL CHIP 33 0.50% 1/10W
R121 1-215-925-11 METAL OXIDE 22K 5% 3W
R131 1-216-809-11 METAL CHIP 100 5% 1/10W
R149 1-216-864-11 SHORT CHIP 0
R150 1-216-809-11 METAL CHIP 100 5% 1/10W
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-853-11 METAL CHIP 470K 5% 1/10W
R154 1-216-821-11 METAL CHIP 1K 5% 1/10W
R155 1-216-837-11 METAL CHIP 22K 5% 1/10W
R203 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R204 1-216-833-11 METAL CHIP 10K 5% 1/10W
R205 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R207 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R210 1-216-837-11 METAL CHIP 22K 5% 1/10W
R212 1-216-864-11 SHORT CHIP 0
R213 1-216-835-11 METAL CHIP 15K 5% 1/10W
R214 1-216-835-11 METAL CHIP 15K 5% 1/10W
R215 1-216-833-11 METAL CHIP 10K 5% 1/10W
R216 1-216-833-11 METAL CHIP 10K 5% 1/10W
R218 1-216-295-91 SHORT CHIP 0
R219 1-249-411-11 CARBON 330 5% 1/4W
R220 1-216-864-11 SHORT CHIP 0
A
