– 62 –
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-BM142M70
RM-W101
R616 1-245-528-11 METAL 1.5 5% 10W
R618 1-249-432-11 CARBON 18K 5% 1/4W
R619 1-216-361-00 METAL OXIDE 0.22 5% 2W
R620 1-243-946-21 METAL OXIDE 0.27 5% 2W
R621 1-249-409-11 CARBON 220 5% 1/4W
R623 1-218-877-11 METAL CHIP 18K 0.50% 1/10W
R624 1-215-429-00 METAL 2.2K 1% 1/4W
R625 1-216-864-11 SHORT CHIP 0
R627 1-249-385-11 CARBON 2.2 5% 1/4W
R631 1-247-847-91 CARBON 4.7K 5% 1/4W
R634 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R635 1-216-833-11 METAL CHIP 10K 5% 1/10W
R636 1-249-421-11 CARBON 2.2K 5% 1/4W
R638 1-245-528-11 METAL 1.5 5% 10W
R645 1-218-899-11 METAL CHIP 150K 0.50% 1/16W
R646 1-218-851-11 METAL CHIP 1.5K 0.50% 1/10W
R647 1-216-821-11 METAL CHIP 1K 5% 1/10W
R650 ! 1-240-917-51 METAL 8.2M 5% 1W
R655 1-216-809-11 METAL CHIP 100 5% 1/10W
R656 1-249-381-11 CARBON 1 5% 1/4W
R658 1-245-464-31 METAL 120K 1% 1/4W
R660 1-245-478-31 METAL 470K 1% 1/4W
R661 1-245-480-31 METAL 560K 1% 1/4W
R667 1-216-821-11 METAL CHIP 1K 5% 1/10W
R668 1-216-839-11 METAL CHIP 33K 5% 1/10W
R820 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R821 1-216-837-11 METAL CHIP 22K 5% 1/10W
R822 1-249-418-11 CARBON 1.2K 5% 1/4W
R823 1-245-468-31 METAL 180K 1% 1/4W
R824 1-216-839-11 METAL CHIP 33K 5% 1/10W
R825 1-243-608-71 METAL OXIDE 1.5K 5% 3W
R826 1-247-891-00 CARBON 330K 5% 1/4W
R827 1-243-542-21 METAL OXIDE 1.5 5% 2W
R828 1-243-608-71 METAL OXIDE 1.5K 5% 3W
R829 1-215-917-21 METAL OXIDE 1K 5% 3W
R830 1-260-332-51 CARBON 2.2K 5% 1/2W
R831 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R833 1-260-125-11 CARBON 150K 5% 1/2W
R834 1-245-468-31 METAL 180K 1% 1/4W
R835 1-260-125-11 CARBON 150K 5% 1/2W
R838 1-216-838-11 METAL CHIP 27K 5% 1/10W
R839 1-216-864-11 SHORT CHIP 0
R843 1-216-864-11 SHORT CHIP 0
R844 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R846 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R847 1-216-833-11 METAL CHIP 10K 5% 1/10W
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R853 1-218-859-11 METAL CHIP 3.3K 0.50% 1/10W
R854 1-218-877-11 METAL CHIP 18K 0.50% 1/10W
R855 1-216-847-11 METAL CHIP 150K 5% 1/10W
R856 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R859 1-218-883-11 METAL CHIP 33K 0.50% 1/10W
R861 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R864 1-218-865-11 METAL CHIP 5.6K 0.50% 1/10W
R865 1-216-821-11 METAL CHIP 1K 5% 1/10W
R866 1-218-895-11 METAL CHIP 100K 0.50% 1/10W
R868 1-249-393-11 CARBON 10 5% 1/4W
R869 1-249-381-11 CARBON 1 5% 1/4W
R870 1-218-855-11 METAL CHIP 2.2K 0.50% 1/10W
R871 1-215-863-11 METAL OXIDE 100 5% 1W
R221 1-216-821-11 METAL CHIP 1K 5% 1/10W
R235 1-249-401-11 CARBON 47 5% 1/4W
R236 1-216-833-11 METAL CHIP 10K 5% 1/10W
R239 1-216-809-11 METAL CHIP 100 5% 1/10W
R241 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R242 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R300 1-216-809-11 METAL CHIP 100 5% 1/10W
R302 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
R303 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
R304 1-216-855-11 METAL CHIP 680K 5% 1/10W
R307 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
R309 1-216-857-11 METAL CHIP 1M 5% 1/10W
R310 1-216-809-11 METAL CHIP 100 5% 1/10W
R311 1-216-841-11 METAL CHIP 47K 5% 1/10W
R312 1-216-857-11 METAL CHIP 1M 5% 1/10W
R313 1-216-847-11 METAL CHIP 150K 5% 1/10W
R314 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R315 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R317 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R320 1-218-863-11 METAL CHIP 4.7K 0.50% 1/10W
R322 1-218-863-11 METAL CHIP 4.7K 0.50% 1/10W
R323 1-216-809-11 METAL CHIP 100 5% 1/10W
R324 1-216-864-11 SHORT CHIP 0
R331 1-216-809-11 METAL CHIP 100 5% 1/10W
R336 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R337 1-216-817-11 METAL CHIP 470 5% 1/10W
R338 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R339 1-216-809-11 METAL CHIP 100 5% 1/10W
R340 1-216-833-11 METAL CHIP 10K 5% 1/10W
R341 1-216-809-11 METAL CHIP 100 5% 1/10W
R355 1-216-837-11 METAL CHIP 22K 5% 1/10W
R356 1-216-864-11 SHORT CHIP 0
R360 1-216-864-11 SHORT CHIP 0
R363 1-216-864-11 SHORT CHIP 0
R364 1-216-821-11 METAL CHIP 1K 5% 1/10W
R379 1-216-843-11 METAL CHIP 68K 5% 1/10W
R380 1-216-809-11 METAL CHIP 100 5% 1/10W
R384 1-216-809-11 METAL CHIP 100 5% 1/10W
R385 1-216-809-11 METAL CHIP 100 5% 1/10W
R386 1-216-809-11 METAL CHIP 100 5% 1/10W
R392 1-216-833-11 METAL CHIP 10K 5% 1/10W
R393 1-216-809-11 METAL CHIP 100 5% 1/10W
R394 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R395 1-216-845-11 METAL CHIP 100K 5% 1/10W
R397 1-216-125-00 RES-CHIP 1.5M 5% 1/10W
R398 1-216-797-11 METAL CHIP 10 5% 1/10W
R400 1-260-288-11 CARBON 0.47 5% 1/2W
R401 1-260-288-11 CARBON 0.47 5% 1/2W
R405 1-260-288-11 CARBON 0.47 5% 1/2W
R406 1-260-127-11 CARBON 220K 5% 1/2W
R411 1-214-909-00 METAL 68K 1% 1/2W
R412 1-214-773-00 METAL 68K 1% 1/4W
R413 1-215-461-00 METAL 47K 1% 1/4W
R414 1-260-336-11 CARBON 4.7K 5% 1/2W
R416 1-260-107-11 CARBON 4.7K 5% 1/2W
R420 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R421 1-216-833-11 METAL CHIP 10K 5% 1/10W
R423 1-216-864-11 SHORT CHIP 0
R424 1-216-845-11 METAL CHIP 100K 5% 1/10W
R602 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R609 1-216-833-11 METAL CHIP 10K 5% 1/10W
R612 1-215-425-00 METAL 1.5K 1% 1/4W
