Sony Trinitron RM-W101 - ICs; Resistors; Connectors

– 63 –
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-BM142M70
RM-W101
R872 1-216-864-11 SHORT CHIP 0
R873 1-216-841-11 METAL CHIP 47K 5% 1/10W
R876 1-216-833-11 METAL CHIP 10K 5% 1/10W
R877 1-218-895-11 METAL CHIP 100K 0.50% 1/10W
R878 1-216-349-00 METAL OXIDE 1 5% 1W
R881 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R882 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R883 1-249-421-11 CARBON 2.2K 5% 1/4W
R887 1-216-837-11 METAL CHIP 22K 5% 1/10W
R888 1-218-887-11 METAL CHIP 47K 0.50% 1/10W
R889 1-243-531-21 METAL OXIDE 100 5% 3W
R890 1-215-900-21 METAL OXIDE 22K 5% 2W
R891 1-249-385-11 CARBON 2.2 5% 1/4W
R893 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R895 1-218-855-11 METAL CHIP 2.2K 0.50% 1/10W
R902 1-216-821-11 METAL CHIP 1K 5% 1/10W
R904 1-216-821-11 METAL CHIP 1K 5% 1/10W
R905 1-216-840-11 METAL CHIP 39K 5% 1/10W
R906 1-216-817-11 METAL CHIP 470 5% 1/10W
R911 1-216-813-11 METAL CHIP 220 5% 1/10W
R914 1-216-853-11 METAL CHIP 470K 5% 1/10W
R915 1-216-849-11 METAL CHIP 220K 5% 1/10W
R917 1-218-285-11 METAL CHIP 75 5% 1/10W
R924 1-216-853-11 METAL CHIP 470K 5% 1/10W
R931 1-216-807-11 METAL CHIP 68 5% 1/10W
R932 1-216-864-11 SHORT CHIP 0
R940 1-216-849-11 METAL CHIP 220K 5% 1/10W
R945 1-216-833-11 METAL CHIP 10K 5% 1/10W
R989 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2646 1-249-381-11 CARBON 1 5% 1/4W
R2647 1-249-429-11 CARBON 10K 5% 1/4W
R8009 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R8010 1-245-464-31 METAL 120K 1% 1/4W
R8011 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8012 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8013 1-245-462-31 METAL 100K 1% 1/4W
R9005 1-216-864-11 SHORT CHIP 0
R9006 1-216-864-11 SHORT CHIP 0
R9007 1-216-864-11 SHORT CHIP 0
R9008 1-216-864-11 SHORT CHIP 0
R9009 1-216-864-11 SHORT CHIP 0
R9017 1-216-809-11 METAL CHIP 100 5% 1/10W
R9018 1-216-809-11 METAL CHIP 100 5% 1/10W
R9019 1-216-809-11 METAL CHIP 100 5% 1/10W
R9020 1-216-809-11 METAL CHIP 100 5% 1/10W
R9021 1-216-809-11 METAL CHIP 100 5% 1/10W
R9022 1-216-809-11 METAL CHIP 100 5% 1/10W
R9023 1-216-809-11 METAL CHIP 100 5% 1/10W
R9025 1-216-809-11 METAL CHIP 100 5% 1/10W
R9027 1-216-838-11 METAL CHIP 27K 5% 1/10W
R9028 1-216-809-11 METAL CHIP 100 5% 1/10W
R9034 1-216-809-11 METAL CHIP 100 5% 1/10W
R9036 1-216-809-11 METAL CHIP 100 5% 1/10W
R9038 1-216-864-11 SHORT CHIP 0
R9040 1-216-857-11 METAL CHIP 1M 5% 1/10W
R9041 1-216-857-11 METAL CHIP 1M 5% 1/10W
R9042 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R9043 1-216-821-11 METAL CHIP 1K 5% 1/10W
R9044 1-216-817-11 METAL CHIP 470 5% 1/10W
R9045 1-216-809-11 METAL CHIP 100 5% 1/10W
R9046 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R9047 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9051 1-216-864-11 SHORT CHIP 0
R9053 1-218-285-11 METAL CHIP 75 5% 1/10W
R9060 1-216-864-11 SHORT CHIP 0
R9061 1-216-864-11 SHORT CHIP 0
<RELAY>
RY600 ! 1-755-198-12 RELAY, AC POWER
<SWITCH>
S600 ! 1-571-433-31 SWITCH, PUSH (AC POWER)
S800 1-572-707-11 SWITCH, LEVER
SWF100 1-781-042-11 FILTER, SURFACE WAVE
<TRANSFORMER>
T600 ! 1-456-354-11 LINE FILTER COIL
T602 ! 1-439-690-11 CONVERTER TRANSFORMER (SRT)
T603 ! 1-456-354-11 LINE FILTER COIL
T800 1-437-936-21 FERRITE TRANSFORMER (HDT)
T802 ! 1-453-309-21 TRANSFORMER ASSY FLYBACK
T802 (NX-4450//M3A4)
<THERMISTOR>
THP600! 1-804-530-11 THERMISTOR, POSITIVE
TP02 1-536-354-00 POST PIN
TP03 1-536-354-00 POST PIN
TP04 1-536-354-00 POST PIN
TP601 1-536-354-00 POST PIN
TP602 1-536-354-00 POST PIN
<TUNER>
TU102 1-693-659-11 TUNER
<VARISTOR>
VDR600 1-804-995-11 VARISTOR
<CRYSTAL>
X001 1-795-839-21 QUARTZ CRYSTAL UNIT
**********************************************************************************
* A-1075-951-A MOUNTED PWB, C
*****************
4-382-854-01 SCREW (M3X8), P, SW (+)
* A702 4-102-022-01 PIN(30), WIRE
* A703 4-102-022-01 PIN(30), WIRE
* A704 4-102-022-01 PIN(30), WIRE
* A705 4-102-022-01 PIN(30), WIRE
<CAPACITOR>
C751 1-107-961-91 ELECT 10UF 20.00% 250V
C752 1-115-350-51 CERAMIC 0.0047UF 2KV
CA
