Sony Trinitron RM-W101 - Variable Resistors; Remote Commander

– 64 –
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-BM142M70
RM-W101
Sony Corporation
Sony EMCS (Malaysia) Sdn. Bhd.
Visual Products
9-872-465-01
English
 2004.8
C754 1-107-651-11 ELECT 4.7UF 20.00% 250V
C781 1-107-960-11 ELECT 4.7UF 20.00% 250V
C782 1-102-074-00 CERAMIC 0.001UF 10.00% 50V
C783 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C786 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C787 1-164-645-11 CERAMIC 1000PF 10.00% 500V
<CONNECTOR>
* CN701 1-564-510-11 PLUG, CONNECTOR 7P
* CN703 1-564-508-11 PLUG, CONNECTOR 5P
CN704 1-695-915-11 TAB (CONTACT)
CN705 1-695-915-11 TAB (CONTACT)
<DIODE>
D750 8-719-908-03 DIODE GP08D
D754 6-500-949-01 DIODE 1SS244-T-72
D755 6-500-949-01 DIODE 1SS244-T-72
D756 6-500-949-01 DIODE 1SS244-T-72
D780 8-719-991-33 DIODE 1SS133T-77
D781 8-719-991-33 DIODE 1SS133T-77
D782 8-719-069-55 DIODE UDZSTE-175.6B
<IC>
IC751 6-703-482-01 IC TDA6108AJF/N1
<JACK>
J751 ! 1-451-544-11 SOCKET, CRT
<COIL>
L780 1-414-742-21 INDUCTOR 22UH
<RESISTOR>
R713 1-216-864-11 SHORT CHIP 0
R752 1-216-819-11 METAL CHIP 680 5% 1/10W
R753 1-216-819-11 METAL CHIP 680 5% 1/10W
R754 1-216-819-11 METAL CHIP 680 5% 1/10W
R756 1-219-746-11 METAL 1K 5% 1/2W
R757 1-219-746-11 METAL 1K 5% 1/2W
R758 1-219-746-11 METAL 1K 5% 1/2W
R763 1-260-316-51 CARBON 100 5% 1/2W
R764 1-260-316-51 CARBON 100 5% 1/2W
R765 1-260-316-51 CARBON 100 5% 1/2W
R773 1-260-132-11 CARBON 560K 5% 1/2W
R774 1-215-912-11 METAL OXIDE 150 5% 3W
R780 1-260-131-11 CARBON 470K 5% 1/2W
R781 1-243-949-21 METAL OXIDE 0.47 5% 2W
R783 1-260-316-51 CARBON 100 5% 1/2W
R794 1-249-377-11 CARBON 0.47 5% 1/4W
R795 1-260-352-11 CARBON 100K 5% 1/2W
<VARIABLE RESISTOR>
RV750 1-241-656-11 RES, ADJ, METAL FILM 110M
**********************************************************************************
<ACCESSORIES AND PACKING MATERIALS>
******************************************
1-417-151-51 MATCHING TRANSFORMER, ANTENNA
1-501-730-41 ANTENNA, TELESCOPIC
* 4-377-015-01 BAG, PROTECTION
* 4-093-804-01 CUSHION, UPPER
* 4-093-805-01 CUSHION, LOWER
* 4-093-806-02 INDIVIDUAL CARTON
2-023-202-11 MANUAL, INSTRUCTION
**********************************************************************************
<REMOTE COMMANDER>
***********************
1-478-009-11 REMOTE COMMANDER (RM-W101)
4-084-290-01 BATTERY COVER REMOTE COMMANDER
C
