Tuners (URX-P1/R1/M1)
Items common to all tuners
Type of reception
Space diversity
Oscillator type
Crystal-controlled PLL
synthesizer
Reception frequencies
Model available in USA:
758 to 806 MHz
Model available in Europe:
798 to 862 MHz
Model available in
Australia: 792 to 806
MHz
Operating frequency band
Model available in USA
and Europe: 24 MHz BW
Model available in
Australia: 14 MHz BW
Signal-to-noise ratio
60 dB or more
De-emphasis
50 µs
Reference deviation
±5 kHz
Frequency characteristics
50 Hz to 18 kHz
Distortion
1.0% or less at 1 kHz
modulation
Tone signal
32 kHz
Indicator RF input level
Portable diversity tuner
(URX-P1)
Antenna 1/4λ wave length wire
(adjustable angle)
Squelch level
15 dBµ
Audio output level
–58 dBm
Audio output connector
3.5 mm dia. mini jack
Headphones output level
5 mW (16Ω)
Display Channel, frequency, audio
level, RF level,
accumulated battery use
time, monitor level
Power requirements
3.0 V DC (two LR6/AA-
size alkaline batteries)
Battery life
Approx. 6 hours (measured
with two Sony LR6/AA-
size alkaline batteries at
25 °C (77°F))
Dimensions
63 × 100 × 30 mm (2
1
/2 × 4
× 1
3
/16 inches) (w/h/d)
(excluding the antennas)
Mass Approx. 180 g (6 oz)
including batteries
