Sony VPL-CW255 - Page 41

41
Specifications
Others
INPUT OUTPUT
(Computer/video)
INPUT A RGB/YPBPR input connector: Mini D-sub 15 pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB, 75
ohms terminated, Sync signal: TTL level high
impedance, positive/negative
Audio input connector: Stereo mini jack, rated input
500 mVrms, input impedance more than 47 kohms
INPUT B RGB input connector: Mini D-sub 15-pin female,
RGB: 0.7 Vp-p ± 2 dB, 75 ohms terminated, Sync signal:
TTL level high impedance, positive/negative
Audio input connector: Stereo mini jack, rated input
500 mVrms, input impedance more than 47 kohms
INPUT C HDMI input connector: HDMI 19-pin, HDCP support,
Audio input connector: HDMI audio support
S VIDEO IN S video input connector: Mini DIN 4-pin, Y: 1 Vp-p
± 2 dB, sync negative, 75 ohmes terminated, C: (burst
signal) 0.286 (NTSC)/0.3 (PAL/SECAM) Vp-p ± 2 dB,
75 ohms terminated
Audio input connector: Phono jack × 2, rated input
500 mVrms, Input impedance more than 47 kohms
VIDEO IN Video input connector: Phono jack, 1 Vp-p ± 2 dB,
sync negative, 75 ohmes terminated
Audio input connector: Shared with S VIDEO IN
OUTPUT MONITOR output connector: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative,
75 ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB,
75 ohms terminated, Sync signal: HD, VD 4 V (open),
1 Vp-p (75 ohms), positive/negative
Audio output connector: Stereo mini jack, stereo,
1 Vrms (maximum volume, when inputting 500 mVrms),
output impedance 5 kohms
Others connector RS-232C connector: D-Sub 9 pin female
LAN connector: RJ45, 10BASE-T/100BASE-TX
Operating
temperature/
Operating
humidity
0 °C to 40 °C (32 °F to 104 °F)/20% to 80% (no
condensation)
Storage
temperature/
Storage humidity
–10 °C to +60 °C (14 °F to 140 °F)/ 20% to 80% (no
condensation)
Power
requirements
100 V to 240 V AC, 3.6 A-1.4 A, 50/60 Hz
Power
consumption
100 V AC: 350 W
240 V AC: 330 W
Item Description
Model VPL-CX235/VPL-CW255
