58 Ceiling Installation
Ceiling Installation
Use the PSS-610 Projector Suspension Support when you install the projector
on a ceiling. The projection distances for ceiling installation are shown below.
When using the 16:9 aspect ratio screen
Unit: mm (inches)
To calculate the installation measurements (SS: Screen Size)
a (minimum) = {(SS × 21.27/0.7227) – 35.160899} × 1.025 + 123.5
a (maximum) = {(SS × 33.9409273/0.7227) – 37.678872} × 0.975 + 123.5
x (minimum) = (SS/0.7227 × 4.5) – 75
x (maximum) = b + (SS/0.7227 × 9) – 75
Screen Size
(inches)
40 60 80 100 120 150 180 200
a Minimum
Distance
1290
(50
7
/8
)
1890
(74
1
/2)
2500
(98
1
/2)
3100
(122
1
/8)
3700
(145
3
/4)
4610
(181
5
/8)
5510
(217)
6120
(241)
Maximum
Distance
1910
(75
1
/4)
2830
(111
1
/2)
3750
(147
3
/4)
4660
(183
1
/2)
5580
(219
3
/4)
6950
(273
3
/4)
8330
(328)
9240
(363
7
/8)
x Minimum
Distance
174
(6
7
/8)
299
(11
7
/8)
423
(16
3
/4)
548
(21
5
/8)
672
(26
1
/2)
859
(33
7
/8)
1046
(41
1
/4)
1170
(46
1
/8)
Maximum
Distance
b+423
(b+16
3
/
4
)
b+672
(b+26
1
/
2
)
b+921
(b+36
3
/
8
)
b+1170
(b+46
1
/
8
)
b+1419
(b+55
7
/
8
)
b+1793
(b+70
5
/
8
)
b+2166
(b+85
3
/
8
)
b+2416
(b+95
1
/
4
)
b 150, 175, 200, 250, 300 mm (6, 7, 7
7
/8, 9
7
/8, 10
7
/8, 11
7
/8 inches) adjustable
when using PSS-610
a
x
b
a: Distance between the screen and the front hole for the mount
bracket on the bottom surface of the unit
b: Distance from the ceiling to the bottom surface of the unit
x: Distance between the ceiling and the center of the screen
PSS-610 Projector Suspension
Support (not supplied)
Ceiling
Center of the
screen
Center of the lens
