1-22 (E)
VPL-VW520
1-8. Optional Fixtures
1-8-1. Extension
1-8-2. Connection
XSP kit (A-1997-987-A)
SH connector assembly
XSP board
CN1701
Bottom side
Peel the sheet.
SH connector
assembly
XSP board
