4-6
VPL-VW520
B
To G board
To Q board
To Q board
PSW
3 ) 8
A
A
To Q board
B
To Power supply block
C
C
BVTP
3 ) 12
(SILVER)
BVTP
3 ) 12
(SILVER)
BVTP
3 ) 12
(SILVER)
BVTP
3 ) 12
(BLACK)
BVTP
3 ) 12
(SILVER)
BVTP
3 ) 12
(SILVER)
BVTP
3 ) 12
(SILVER)
BVTP
3 ) 12
(SILVER)
BVTP
3 ) 12
(SILVER)
BVTP
3 ) 12
(BLACK)
BVTP
3 ) 12
(SILVER)
207
207
207
204
209
207
207
208
210
202
203
207
206
201
205
DC Fan Block
