9
WM-EX921
3-7. ORNAMENT (OPEN) BLOCK ASSY
3-8. HOLDER (FA) ASSY
2
claw
4
two claws
5
ornament (open) block assy
3
boss
1
1
7
bracket (cassette/910) assy
2
boss
6
boss
3
lever (B) (/M), loc
k
5
lever (S) (/M), lock
1
two screws (M1.4)
4
screws (M1.4)
8
Remove six solders of
head flexible board.
9
holder (FA) assy
