Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 23 —
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
MX : Mexican model
When indicating parts by reference number,
please include the board name.
SECTION 8
ELECTRICAL PARTS LIST
A-3021-212-A MAIN BOARD, COMPLETE (US,CND,MX)
********************
A-3021-214-A MAIN BOARD, COMPLETE (AEP,E)
********************
3-386-374-01 SCREW(1.7)
3-934-003-01 JOINT(TUNE)
3-934-023-01 JOINT(VOL)
7-627-850-57 SCREW,PRECISION +P 1.4 × 3.5
< BATTERY >
BT1 3-921-878-01 TERMINAL BOARD, BATTERY
BT2 3-032-149-01 SPRING, BATTERY COIL
< CAPACITOR >
C1 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C2 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C3 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C4 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C5 1-162-911-11 CERAMIC CHIP 6PF 0.5PF 50V
C6 1-162-997-11 CERAMIC CHIP 10PF 0.5PF 50V
C7 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C8 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C9 1-162-939-11 CERAMIC CHIP 8PF 0.5PF 50V
(US,CND,MX)
C9 1-162-997-11 CERAMIC CHIP 10PF 0.5PF 50V
(AEP,E)
C10 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C11 1-115-156-11 CERAMIC CHIP 1uF 10V
C12 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C13 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C14 1-115-156-11 CERAMIC CHIP 1uF 10V
C17 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C18 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US,CND,MX)
C18 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(AEP,E)
C19 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US,CND,MX)
C19 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(AEP,E)
C20 1-124-433-00 ELECT 100uF 20% 4V
C22 1-109-935-11 TANTAL. CHIP 4.7uF 20% 4V
C23 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C25 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
(US,CND,MX)
C26 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C27 1-115-156-11 CERAMIC CHIP 1uF 10V
C28 1-163-205-00 CERAMIC CHIP 0.001uF 5% 50V
C29 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C30 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C31 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C101 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C102 1-164-505-11 CERAMIC CHIP 2.2uF 1 6V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C104 1-126-153-11 ELECT 22uF 20% 6.3V
C105 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C106 1-115-156-11 CERAMIC CHIP 1uF 10V
C107 1-164-346-11 CERAMIC CHIP 1uF 16V
C108 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C109 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C201 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C202 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C204 1-126-153-11 ELECT 22uF 20% 6.3V
C205 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C206 1-115-156-11 CERAMIC CHIP 1uF 10V
C207 1-115-156-11 CERAMIC CHIP 1uF 10V
C208 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C301 1-115-156-11 CERAMIC CHIP 1uF 10V
C302 1-115-156-11 CERAMIC CHIP 1uF 10V
C305 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C306 1-124-433-00 ELECT 100uF 20% 4V
C307 1-115-156-11 CERAMIC CHIP 1uF 10V
C308 1-115-156-11 CERAMIC CHIP 1uF 10V
C309 1-124-433-00 ELECT 100uF 20% 4V
C310 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C311 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C312 1-164-346-11 CERAMIC CHIP 1uF 16V
C313 1-115-156-11 CERAMIC CHIP 1uF 10V
C314 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C315 1-126-153-11 ELECT 22uF 20% 6.3V
C316 1-126-153-11 ELECT 22uF 20% 6.3V
C317 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C318 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C319 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C320 1-163-063-00 CERAMIC CHIP 0.022uF 50V
C601 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C602 1-135-187-21 TANTAL. CHIP 2.2uF 20% 4V
C603 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C604 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
MAIN
