Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 24 —
MAIN
C605 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C606 1-124-434-00 ELECT 220uF 20% 4V
C607 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C608 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C609 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C610 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
< FILTER >
CF1 1-781-300-21 FILTER, CERAMIC (450kHz)
CF2 1-767-736-71 FILTER ASSY, CERAMIC (10.7MHz)
< CONNECTOR >
CN303 1-750-346-21 CONNECTOR, FFC/EPC (ZIF) 6P
< VARIABLE CAPACITOR >
CV1 1-151-653-11 CAP, VARIABLE (US,CND,MX)
CT1-4 1-151-653-11 CAP, ADJ (US,CND,MX)
CV1 1-151-654-11 CAP, VARIABLE (AEP,E)
CT1-4 1-151-654-11 CAP, ADJ (AEP,E)
< DIODE >
D301 8-719-984-02 LED BR4371F (BATT)
< FERRITE BEAD >
FB101 1-414-760-21 FERRITE 0uH
FB201 1-414-760-21 FERRITE 0uH
FB301 1-414-813-11 FERRITE 0uH
< FILTER >
FL1 1-236-711-21 FILTER, BAND PASS
< IC >
IC1 8-759-493-20 IC TA2111F-(EL)
IC301 8-759-821-89 IC LA4571M-T1
IC601 8-759-447-73 IC LB1979V-TLM
< JUMPER CHIP >
JC1 1-216-296-91 SHORT 0
JC2 1-216-296-91 SHORT 0
JC3 1-216-296-91 SHORT 0
JC4 1-216-296-91 SHORT 0
JC5 1-216-296-91 SHORT 0
JC6 1-216-296-91 SHORT 0
JC7 1-216-296-91 SHORT 0
JC8 1-216-296-91 SHORT 0
JC9 1-216-296-91 SHORT 0
JC10 1-216-296-91 SHORT 0
JC11 1-216-296-91 SHORT 0
JC12 1-216-296-91 SHORT 0
JC14 1-216-296-91 SHORT 0
JC15 1-216-296-91 SHORT 0
JC16 1-216-296-91 SHORT 0
JC17 1-216-296-91 SHORT 0
JC18 1-216-296-91 SHORT 0
JC19 1-216-296-91 SHORT 0
JC20 1-216-296-91 SHORT 0
JC21 1-216-296-91 SHORT 0
JC22 1-216-296-91 SHORT 0
JC23 1-216-296-91 SHORT 0
JC24 1-216-296-91 SHORT 0
JC25 1-216-296-91 SHORT 0
JC26 1-216-296-91 SHORT 0
JC27 1-216-296-91 SHORT 0
JC28 1-216-296-91 SHORT 0
JC31 1-216-295-91 SHORT 0
JC32 1-216-295-91 SHORT 0
JC33 1-216-295-91 SHORT 0
JC41 1-216-864-11 METAL CHIP 0 5% 1/16W
JC42 1-216-864-11 METAL CHIP 0 5% 1/16W
JC43 1-216-864-11 METAL CHIP 0 5% 1/16W
JC44 1-216-864-11 METAL CHIP 0 5% 1/16W
JC47 1-216-864-11 METAL CHIP 0 5% 1/16W
JC50 1-216-864-11 METAL CHIP 0 5% 1/16W
JC51 1-216-864-11 METAL CHIP 0 5% 1/16W
JC52 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L1 1-754-052-11 ANTENNA, FERRITE-ROD
L2 1-416-960-11 COIL(WITH CORE)
L3 1-416-959-11 COIL(WITH CORE)
L4 1-416-958-11 COIL(OSC)
< TRANSISTOR >
Q1 8-729-231-74 TRANSISTOR 2SC4116GL-TE85L (US,CND,MX)
Q2 8-729-230-60 TRANSISTOR 2SA1586YG-TE85L
Q3 8-729-014-12 TRANSISTOR RN1311-TE85L
Q4 8-729-014-12 TRANSISTOR RN1311-TE85L
Q5 8-729-014-12 TRANSISTOR RN1311-TE85L
Q6 8-729-028-76 TRANSISTOR RN2307-TE85L
Q7 8-729-014-12 TRANSISTOR RN1311-TE85L (AEP,E)
Q8 8-729-028-76 TRANSISTOR RN2307-TE85L (AEP,E)
Q101 8-729-421-26 TRANSISTOR RN1310-TE85L
Q102 8-729-231-74 TRANSISTOR 2SC4116GL-TE85L
Q103 8-729-231-74 TRANSISTOR 2SC4116GL-TE85L
Q104 8-729-421-26 TRANSISTOR RN1310-TE85L
Q201 8-729-421-26 TRANSISTOR RN1310-TE85L
Q202 8-729-231-74 TRANSISTOR 2SC4116GL-TE85L
Q203 8-729-231-74 TRANSISTOR 2SC4116GL-TE85L
Q204 8-729-421-26 TRANSISTOR RN1310-TE85L
Q301 8-729-014-12 TRANSISTOR RN1311-TE85L
Q304 8-729-014-12 TRANSISTOR RN1311-TE85L
Q305 8-729-014-12 TRANSISTOR RN1311-TE85L
Q306 8-729-014-86 TRANSISTOR 2SC4207-YGRTE85L
Q307 8-729-230-72 TRANSISTOR 2SA1362-YG-EL
Q308 8-729-014-12 TRANSISTOR RN1311-TE85L
< RESISTOR >
R1 1-216-821-11 METAL CHIP 1K 5% 1/16W
(US,CND,MX)
R2 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R3 1-216-835-11 METAL CHIP 15K 5% 1/16W
R4 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R6 1-216-815-11 METAL CHIP 330 5% 1/16W
R8 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R9 1-216-845-11 METAL CHIP 100K 5% 1/16W
R13 1-216-835-11 METAL CHIP 15K 5% 1/16W
R14 1-216-835-11 METAL CHIP 15K 5% 1/16W
R103 1-216-855-11 METAL CHIP 680K 5% 1/16W
