Sony WM-FS111 User Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 25 —
R104 1-216-835-11 METAL CHIP 15K 5% 1/16W
R105 1-216-819-11 METAL CHIP 680 5% 1/16W
R107 1-216-864-11 METAL CHIP 0 5% 1/16W
R108 1-216-811-11 METAL CHIP 150 5% 1/16W
R109 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R110 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R111 1-216-811-11 METAL CHIP 150 5% 1/16W
R112 1-216-849-11 METAL CHIP 220K 5% 1/16W
R113 1-216-202-00 RES,CHIP 1.5K 5% 1/8W
R114 1-216-835-11 METAL CHIP 15K 5% 1/16W
R115 1-216-835-11 METAL CHIP 15K 5% 1/16W
R203 1-216-855-11 METAL CHIP 680K 5% 1/16W
R204 1-216-835-11 METAL CHIP 15K 5% 1/16W
R205 1-216-819-11 METAL CHIP 680 5% 1/16W
R207 1-216-864-11 METAL CHIP 0 5% 1/16W
R208 1-216-811-11 METAL CHIP 150 5% 1/16W
R209 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R210 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R211 1-216-811-11 METAL CHIP 150 5% 1/16W
R212 1-216-849-11 METAL CHIP 220K 5% 1/16W
R213 1-216-202-00 RES,CHIP 1.5K 5% 1/8W
R214 1-216-835-11 METAL CHIP 15K 5% 1/16W
R215 1-216-835-11 METAL CHIP 15K 5% 1/16W
R301 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R302 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R303 1-216-817-11 METAL CHIP 470 5% 1/16W
R304 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R305 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R308 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R309 1-216-833-91 RES,CHIP 10K 5% 1/16W
R310 1-216-845-11 METAL CHIP 100K 5% 1/16W
R311 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R312 1-216-821-11 METAL CHIP 1K 5% 1/16W
R313 1-216-194-00 METAL CHIP 680 5% 1/8W
R314 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R315 1-216-841-11 METAL CHIP 47K 5% 1/16W
R601 1-216-821-11 METAL CHIP 1K 5% 1/16W
R602 1-216-845-11 METAL CHIP 100K 5% 1/16W
R603 1-216-821-11 METAL CHIP 1K 5% 1/16W
R604 1-216-833-91 RES,CHIP 10K 5% 1/16W
R605 1-216-821-11 METAL CHIP 1K 5% 1/16W
R606 1-216-857-11 METAL CHIP 1M 5% 1/16W
R607 1-216-857-11 METAL CHIP 1M 5% 1/16W
R608 1-216-857-11 METAL CHIP 1M 5% 1/16W
R609 1-216-821-11 METAL CHIP 1K 5% 1/16W
R611 1-216-821-11 METAL CHIP 1K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-225-184-11 RES, VAR, CARBON 10K/10K (∑VOL)
RV601 1-241-916-11 RES, ADJ, CARBON 4.7K
< SWITCH >
S301 1-692-605-31 SWITCH, SLIDE (FUNCTION)
S302 1-771-092-21 SWITCH, PUSH (1 KEY) (0/(/))
S304 1-762-624-11 SWITCH, SLIDE (TAPE/FM SENS) (US,CND,MX)
S304 1-762-624-11 SWITCH, SLIDE (TAPE/FM MODE) (AEP,E)
S305 1-771-586-11 SWITCH, LEVER (SLIDE) (AVLS)
S306 1-771-586-11 SWITCH, LEVER (SLIDE) (MEGA BASS)
< TRANSFORMER >
T1 1-411-722-11 TRANSFORMER, IF
< THERMISTOR >
TH601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X2 1-767-736-71 FILTER ASSY, CERAMIC (10.7MHz)
************************************************************
* 1-672-324-11 HEADPHONE BOARD
****************
< JACK >
J301 1-565-376-11 JACK (2)
************************************************************
MISCELLANEOUS
*************
BT1 3-921-878-01 TERMINAL BOARD, BATTERY
BT2 3-032-149-01 SPRING, BATTERY COIL
HP301 1-500-517-11 HEAD, MAGNETIC (PLAYBACK)
M901 1-763-073-11 MOTOR (REEL/CAPSTAN) (WITH PULLEY)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
3-032-171-01 CLIP(BELT)
3-037-307-01 STOPPER (BUCKLE)
3-326-162-08 WASHER, POLYETHYLENE, SLIT
3-378-331-21 SCREW,CARRYING CASE
3-864-882-11 MANUAL, INSTRUCTION
(ENGLISH/FRENCH/GERMAN/ITALIAN)
(US,CND,AEP)
3-864-882-21 MANUAL, INSTRUCTION
(SPANISH/PORTUGUESE/DUTCH/
SWEDISH/FINNISH)(AEP)
3-864-882-31 MANUAL, INSTRUCTION
(ENGLISH/SPANISH/TRADITIONAL CHINESE/
KOREAN)(E)
3-864-882-41 MANUAL, INSTRUCTION (SPANISH) (MX)
8-953-284-90 HEADPHONE MDR-W014LP/RK SET
(BLACK)(CND)
8-953-284-91 HEADPHONE MDR-W014LP/YK SET (YELLOW)
8-953-284-92 HEADPHONE MDR-W014LP/LK SET(BLUE)
(CND)
MAIN HEADPHONE
