Sony WM-FX271

– 19 –
6-2. TAPE MECHANISM SECTION-1
(MF-WMFX171-114)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
54
53
55
56
52
51
M901
HP901
51 3-013-560-11 BELT
52 3-703-816-31 SCREW (M1.4), SPECIAL HEAD
53 3-921-042-01 GEAR (REEL)
54 3-703-816-73 SCREW (M1.4), SPECIAL HEAD
55 X-3369-749-7 PINCH LEVER (N) ASSY
56 3-920-996-01 SPRING (PINCH N)
HP901 1-500-532-11 HEAD, MAGNETIC (PLAYBACK)
M901 1-763-073-11 MOTOR (CAPSTAN/REEL) (including PULLEY)
