Sony WM-FX271

– 10 –
Ref. No. Part No. Description Remark
MAIN
Sony Corporation
Personal Audio Company
9-926-958-81
WM-FX271/FX275
99H0482-1
Printed in Japan C1999. 8
Published by General Engineering Dept.
R701 1-216-837-11 METAL CHIP 22K 5% 1/16W
(EXCEPT EE)
R701 1-216-842-11 METAL CHIP 56K 5% 1/16W
(EE)
R702 1-216-839-11 METAL CHIP 33K 5% 1/16W
(EXCEPT EE)
R702 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EE)
R703 1-216-812-11 METAL CHIP 180 5% 1/16W
(EXCEPT EE)
R703 1-216-815-11 METAL CHIP 330 5% 1/16W
(EE)
R704 1-216-803-11 METAL CHIP 33 5% 1/16W
R705 1-216-833-11 RES,CHIP 10K 5% 1/16W
(EXCEPT EE)
R706 1-216-833-11 RES,CHIP 10K 5% 1/16W
R707 1-216-833-11 RES,CHIP 10K 5% 1/16W
R708 1-216-833-11 RES,CHIP 10K 5% 1/16W
R709 1-216-833-11 RES,CHIP 10K 5% 1/16W
R710 1-216-833-11 RES,CHIP 10K 5% 1/16W
R711 1-216-833-11 RES,CHIP 10K 5% 1/16W
R712 1-216-833-11 RES,CHIP 10K 5% 1/16W
R715 1-216-841-11 METAL CHIP 47K 5% 1/16W
R719 1-216-833-11 RES,CHIP 10K 5% 1/16W
R720 1-218-879-11 METAL CHIP 22K 0.50% 1/16W
R721 1-218-915-11 METAL CHIP 680K 0.50% 1/16W
R723 1-216-845-11 METAL CHIP 100K 5% 1/16W
R725 1-216-845-11 METAL CHIP 100K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-225-748-21 RES, VAR, CARBON 10K/10K (VOLUME)
RV601 1-241-784-11 RES, ADJ, CARBON 5K
< SWITCH >
S301 1-762-742-31 SWITCH, DETECTION (SMALL TYPE)
(TAPE POWER)
S303 1-692-298-11 SWITCH, SLIDE (NORM•CrO2/METAL,
DX•LOCAL) (US,CND,C&SA)
S303 1-692-298-11 SWITCH, SLIDE (NORM•CrO2/METAL,
ST•FM MONO) (EXCEPT US,CND,C&SA)
S305 1-692-298-11 SWITCH, SLIDE (AVLS)
S716 1-572-922-11 SWITCH, SLIDE (HOLD ·)
< TRANSFORMER >
T1 1-406-694-11 COIL, AM IFT
T301 1-426-917-11 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR (POSITIVE) >
TH601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X2 1-781-137-11 FILTER ASSY, CERAMIC
X701 1-577-262-11 VIBRATOR, CRYSTAL (75kHz)
