– 9 –
L3
FM TUNING
VOLTAGE
ADJUSTMENT
L2
FM TRACKING
ADJUSTMENT
L4
AM TUNING
VOLTAGE
ADJUSTMENT
T1
AM IF
ADJUSTMENT
CT1
AM TRACKING
ADJUSTMENT
L1
Adjustment Location: main board
Measurement Points: main board
(FM RF IN)
(VT)
FM RF INVT
