Sony WM-FX522 User Manual

4
WM-FX522
SLIDER (NRA) Rotation system
Rotation system during PLAY
Rotation system during FF Rotation system during REW
slider (NRA)
side F
side R
center
insert flywheel (N)
insert flywheel (R)
reverse pulley
clutch assy (F)
g
ear (Y)
cam gear
gear (REEL)
(T side)
motor pulley
idler (A) gear (T side)
gear (FR)
(FF: left side)
insert flywheel (N)
insert flywheel (R)
reverse pulley
clutch assy (F)
gear (Y)
cam gear
gear (REEL) (T side)
motor pulle
y
idler (A) gear (T side)
gear (NR)
(FWD: left side
REW: right side)
idler (B) gear
idler (A) gear (S side)
gear (REEL) (S side)
insert flywheel (N)
insert flywheel (R)
reverse pulley
clutch assy (F)
gear (Y)
cam gear
motor pulley
gear (FR)
(REW: right side)
idler (A) gear (S side)
gear (REEL) (S side)
