WM-FX522
9
3-7. MAIN BOARD
NOTE FOR INSTALLATION
• MAIN BOARD
2
screw
(M1.4)
flexible board
1
Remove six solders
of flexible board.
1
Remove two solders
of plunger solenoid.
1
Remove four solders
of motor.
1
Remove four solders
of leaf switch.
3
main board
slider (NRA)
S703
main boar
d
On installation main board,
adjust the S703 and
slider (NRA).
