– 40 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C31 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C32 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C33 1-164-850-11 CERAMIC CHIP 18PF 5% 16V
C34 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C35 1-164-858-11 CERAMIC CHIP 22PF 5% 16V
C36 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C37 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C38 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C39 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C40 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C41 1-164-930-11 CERAMIC CHIP 330PF 5% 16V
C42 1-164-346-11 CERAMIC CHIP 1uF 16V
C43 1-115-156-11 CERAMIC CHIP 1uF 10V
C44 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C46 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C47 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C48 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C49 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C50 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C51 1-164-839-11 CERAMIC CHIP 0.5PF 0.25PF 16V
C55 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C56 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C57 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C59 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C65 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C83 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C84 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C85 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C86 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C87 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C88 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C89 1-115-156-11 CERAMIC CHIP 1uF 10V
C90 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C91 1-115-156-11 CERAMIC CHIP 1uF 10V
C92 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C93 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C94 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C95 1-115-156-11 CERAMIC CHIP 1uF 10V
C96 1-115-156-11 CERAMIC CHIP 1uF 10V
C97 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C98 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C101 1-135-316-11 TANTAL. CHIP 22uF 20% 2.5V
C102 1-104-908-11 TANTAL. CHIP 47uF 20% 2.5V
C103 1-135-221-11 TANTAL. CHIP 3.3uF 20% 4V
C104 1-107-520-11 TANTAL. CHIP 33uF 20% 2.5V
C109 1-107-685-11 TANTAL. CHIP 15uF 20% 6.3V
C110 1-164-346-11 CERAMIC CHIP 1uF 16V
C111 1-109-935-11 TANTAL. CHIP 4.7uF 20% 6.3V
C112 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
< FILTER >
CF1 1-767-357-11 FILTER, CERAMIC (10.7MHz)
CF2 1-767-313-11 FILTER, CERAMIC (10.7MHz)
CF3 1-767-313-11 FILTER, CERAMIC (10.7MHz)
CF4 1-767-480-11 FILTER, CERAMIC (AM) (450kHz)
< TRIMMER >
CT1 1-141-327-11 CAP, CHIP TYPE TRIMMER 10PF
< DIODE >
D1 8-719-053-30 DIODE MA2S357- (TX). SO
D2 8-719-053-30 DIODE MA2S357- (TX). SO
D3 8-719-053-30 DIODE MA2S357- (TX). SO
D4 8-719-053-30 DIODE MA2S357- (TX). SO
D5 8-719-055-61 DIODE HVR100-9TRU
D6 8-719-055-61 DIODE HVR100-9TRU
D7 8-719-056-88 DIODE UDZ-TE-17-11B
D8 8-719-420-51 DIODE MA729
D9 8-719-404-49 DIODE MA111
< BAND PASS FILTER >
FL1 1-233-260-11 FILTER, BAND PASS
< IC >
IC1 8-759-245-96 IC TA8182FN
IC2 8-759-362-25 IC TA-2022AFN-EL
< COIL >
L5 1-409-837-11 COIL (WITH CORE) (IF)
L7 1-412-006-31 INDUCTOR CHIP 10uH
L8 1-501-872-11 ANTENNA, FERRITE-ROD (MW)
L9 1-412-006-31 INDUCTOR CHIP 10uH
L11 1-412-006-31 INDUCTOR CHIP 10uH
L12 1-414-404-11 INDUCTOR 100uH
L13 1-412-006-31 INDUCTOR CHIP 10uH
L14 1-414-398-11 INDUCTOR 10uH
< TRANSISTOR >
Q1 8-729-037-89 TRANSISTOR 2SC4627J-C (TX).SO
Q2 8-729-037-89 TRANSISTOR 2SC4627J-C (TX).SO
Q3 8-729-028-69 TRANSISTOR 2SC4655-BC (TX)
Q4 8-729-028-69 TRANSISTOR 2SC4655-BC (TX)
Q5 8-729-037-89 TRANSISTOR 2SC4627J-C (TX).SO
Q6 8-729-037-63 TRANSISTOR UN9115J- (TX).SO
Q7 8-729-037-71 TRANSISTOR UN9210J- (TX).SO
Q9 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q12 8-729-425-46 TRANSISTOR XP4315-TXE
Q15 8-729-231-96 TRANSISTOR 2SK880GR-TE85L
Q16 8-729-028-69 TRANSISTOR 2SC4655-BC (TX)
Q17 8-729-800-37 TRANSISTOR 2SD1048-X7
Q18 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q19 8-729-400-55 TRANSISTOR 2SD1328-S
Q20 8-729-425-25 TRANSISTOR XN4604-TX
< RESISTOR >
R1 1-218-985-11 METAL CHIP 470K 5% 1/16W
R2 1-218-985-11 METAL CHIP 470K 5% 1/16W
R3 1-218-985-11 METAL CHIP 470K 5% 1/16W
R4 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5 1-218-985-11 METAL CHIP 470K 5% 1/16W
R6 1-218-985-11 METAL CHIP 470K 5% 1/16W
R7 1-218-985-11 METAL CHIP 470K 5% 1/16W
R8 1-218-985-11 METAL CHIP 470K 5% 1/16W
R10 1-218-965-11 METAL CHIP 10K 5% 1/16W
R11 1-218-965-11 METAL CHIP 10K 5% 1/16W
R12 1-218-949-11 METAL CHIP 470 5% 1/16W
TUNER
