– 41 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R13 1-218-949-11 METAL CHIP 470 5% 1/16W
R14 1-218-947-11 METAL CHIP 330 5% 1/16W
R15 1-218-975-11 METAL CHIP 68K 5% 1/16W
R16 1-218-947-11 METAL CHIP 330 5% 1/16W
R17 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R18 1-218-965-11 METAL CHIP 10K 5% 1/16W
R19 1-218-977-11 METAL CHIP 100K 5% 1/16W
R20 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R21 1-218-941-11 METAL CHIP 100 5% 1/16W
R22 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R23 1-218-945-11 METAL CHIP 220 5% 1/16W
R24 1-218-965-11 METAL CHIP 10K 5% 1/16W
R25 1-218-985-11 METAL CHIP 470K 5% 1/16W
R26 1-218-973-11 METAL CHIP 47K 5% 1/16W
R28 1-218-969-11 METAL CHIP 22K 5% 1/16W
R29 1-218-965-11 METAL CHIP 10K 5% 1/16W
R30 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R31 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R32 1-218-977-11 METAL CHIP 100K 5% 1/16W
R33 1-218-977-11 METAL CHIP 100K 5% 1/16W
R38 1-218-985-11 METAL CHIP 470K 5% 1/16W
R39 1-218-949-11 METAL CHIP 470 5% 1/16W
R61 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R63 1-218-965-11 METAL CHIP 10K 5% 1/16W
R64 1-218-953-11 METAL CHIP 1.0K 5% 1/16W
R65 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R66 1-218-977-11 METAL CHIP 100K 5% 1/16W
R67 1-218-965-11 METAL CHIP 10K 5% 1/16W
R69 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R70 1-218-949-11 METAL CHIP 470 5% 1/16W
R71 1-218-937-11 METAL CHIP 47 5% 1/16W
R72 1-218-951-11 METAL CHIP 680 5% 1/16W
R73 1-218-985-11 METAL CHIP 470K 5% 1/16W
R74 1-218-949-11 METAL CHIP 470 5% 1/16W
R75 1-218-973-11 METAL CHIP 47K 5% 1/16W
R101 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R102 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R103 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
< VARIABLE RESISTOR >
RV1 1-223-578-11 RES, ADJ, METAL GLAZE 22K
< TRANSFORMER >
T1 1-406-404-11 COIL (MW OSCILATION)
T2 1-411-603-11 COIL (AM-MIX)
T3 1-429-324-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
MISCELLANEOUS
**************
* 65 1-694-030-11 CONDUCTIVE BOARD, CONNECTION
* 66 1-668-361-11 AUDIO SWITCH UNIT BOARD
HP901 1-500-280-11 HEAD, MAGNETIC (PLAYBACK)
M901 1-698-885-11 MOTOR (REEL/CAPSTAN)
ND501 1-801-894-11 DISPLAY PANEL, LIQUID CRYSTAL
PM901 1-454-674-31 SOLENOID, PLUNGER
S710 1-762-582-11 SWITCH, LEAF (ATS)
************************************************************
ACCESSORIES & PACKING MATERIALS
**********************************
1-475-182-11 REMOTE CONTROL UNIT (RM-WMF655)
1-528-543-11 BATTERY, NICKEL CADMIUM
(NC-6WM)(Korean)
1-528-543-22 BATTERY, NI-CD (NC-6WM)
! 1-528-580-11 BATTERY CHARGER (BC-7HT) (Tourist)
! 1-528-661-11 BATTERY CHARGER (BC-7DR) (Korean)
1-569-007-11 ADAPTOR, CONVERSION 2P (Tourist)
1-759-043-11 BATTERY CASE
3-008-521-01 CASE, BATTERY CHARGE
3-861-031-01 MANUAL, INSTRUCTION
(JAPANESE, ENGLISH) (Tourist)
3-861-031-11 MANUAL, INSTRUCTION (ENGLISH)
3-918-892-01 CASE, CARRYING
3-920-201-01 CLIP
8-953-219-90 HEADPHONE MDR-ED132MP//K SET
TUNER
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
