Sony XR-C7200R Service Manual

– 49 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R117 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R118 1-216-073-00 METAL CHIP 10K 5% 1/10W
R121 1-216-097-00 RES,CHIP 100K 5% 1/10W
R122 1-216-097-00 RES,CHIP 100K 5% 1/10W
R123 1-216-097-00 RES,CHIP 100K 5% 1/10W
R124 1-216-097-00 RES,CHIP 100K 5% 1/10W
R125 1-216-097-00 RES,CHIP 100K 5% 1/10W
R126 1-216-097-00 RES,CHIP 100K 5% 1/10W
R130 1-216-113-00 METAL CHIP 470K 5% 1/10W
R131 1-216-119-00 METAL CHIP 820K 5% 1/10W
R150 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R151 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R152 1-216-097-00 RES,CHIP 100K 5% 1/10W
R153 1-216-097-00 RES,CHIP 100K 5% 1/10W
R160 1-216-150-00 RES,CHIP 10 5% 1/8W
R201 1-216-150-00 RES,CHIP 10 5% 1/8W
R202 1-216-150-00 RES,CHIP 10 5% 1/8W
R203 1-216-150-00 RES,CHIP 10 5% 1/8W
R204 1-216-150-00 RES,CHIP 10 5% 1/8W
R205 1-216-073-00 METAL CHIP 10K 5% 1/10W
R206 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R207 1-216-049-11 RES,CHIP 1K 5% 1/10W
R230 1-216-097-00 RES,CHIP 100K 5% 1/10W
R231 1-216-097-00 RES,CHIP 100K 5% 1/10W
R232 1-216-027-00 METAL CHIP 120 5% 1/10W
R233 1-216-109-00 METAL CHIP 330K 5% 1/10W
R234 1-216-079-00 METAL CHIP 18K 5% 1/10W
R235 1-216-077-00 METAL CHIP 15K 5% 1/10W
R236 1-216-089-00 RES,CHIP 47K 5% 1/10W
R240 1-216-097-00 RES,CHIP 100K 5% 1/10W
R241 1-216-097-00 RES,CHIP 100K 5% 1/10W
R242 1-216-027-00 METAL CHIP 120 5% 1/10W
R243 1-216-109-00 METAL CHIP 330K 5% 1/10W
R244 1-216-079-00 METAL CHIP 18K 5% 1/10W
R245 1-216-077-00 METAL CHIP 15K 5% 1/10W
R246 1-216-089-00 RES,CHIP 47K 5% 1/10W
R250 1-216-682-11 METAL CHIP 20K 0.5% 1/10W
R251 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R252 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R253 1-216-113-00 METAL CHIP 470K 5% 1/10W
R261 1-216-081-00 METAL CHIP 22K 5% 1/10W
R301 1-216-077-00 METAL CHIP 15K 5% 1/10W
R303 1-216-073-00 METAL CHIP 10K 5% 1/10W
R304 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R305 1-216-295-00 SHORT 0
R306 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R311 1-216-049-11 RES,CHIP 1K 5% 1/10W
R312 1-216-049-11 RES,CHIP 1K 5% 1/10W
R321 1-216-214-00 RES,CHIP 4.7K 5% 1/8W
R322 1-216-214-00 RES,CHIP 4.7K 5% 1/8W
R331 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R332 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R333 1-216-033-00 METAL CHIP 220 5% 1/10W
R334 1-216-089-00 RES,CHIP 47K 5% 1/10W
R341 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R342 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R343 1-216-033-00 METAL CHIP 220 5% 1/10W
R344 1-216-089-00 RES,CHIP 47K 5% 1/10W
R401 1-216-077-00 METAL CHIP 15K 5% 1/10W
R403 1-216-073-00 METAL CHIP 10K 5% 1/10W
R404 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R405 1-216-295-00 SHORT 0
R406 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R411 1-216-049-11 RES,CHIP 1K 5% 1/10W
R412 1-216-049-11 RES,CHIP 1K 5% 1/10W
R431 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R432 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R433 1-216-033-00 METAL CHIP 220 5% 1/10W
R434 1-216-089-00 RES,CHIP 47K 5% 1/10W
R441 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R442 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R443 1-216-033-00 METAL CHIP 220 5% 1/10W
R444 1-216-089-00 RES,CHIP 47K 5% 1/10W
R501 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R505 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R506 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R507 1-216-097-00 RES,CHIP 100K 5% 1/10W
R508 1-216-097-00 RES,CHIP 100K 5% 1/10W
R509 1-216-097-00 RES,CHIP 100K 5% 1/10W
R510 1-216-049-11 RES,CHIP 1K 5% 1/10W
R511 1-216-037-00 METAL CHIP 330 5% 1/10W
R512 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R513 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R514 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R515 1-216-097-00 RES,CHIP 100K 5% 1/10W
R520 1-216-097-00 RES,CHIP 100K 5% 1/10W
R521 1-216-097-00 RES,CHIP 100K 5% 1/10W
R522 1-216-097-00 RES,CHIP 100K 5% 1/10W
R523 1-216-097-00 RES,CHIP 100K 5% 1/10W
R525 1-216-097-00 RES,CHIP 100K 5% 1/10W
R527 1-216-097-00 RES,CHIP 100K 5% 1/10W
R530 1-216-097-00 RES,CHIP 100K 5% 1/10W
R531 1-216-049-11 RES,CHIP 1K 5% 1/10W
R532 1-216-049-11 RES,CHIP 1K 5% 1/10W
R533 1-216-049-11 RES,CHIP 1K 5% 1/10W
R551 1-216-097-00 RES,CHIP 100K 5% 1/10W
R552 1-216-049-11 RES,CHIP 1K 5% 1/10W
R560 1-216-049-11 RES,CHIP 1K 5% 1/10W
R571 1-216-025-00 RES,CHIP 100 5% 1/10W
R572 1-216-025-00 RES,CHIP 100 5% 1/10W
R573 1-216-073-00 METAL CHIP 10K 5% 1/10W
R574 1-216-206-00 RES,CHIP 2.2K 5% 1/8W
R576 1-216-097-00 RES,CHIP 100K 5% 1/10W
R577 1-216-089-00 RES,CHIP 47K 5% 1/10W
R578 1-216-017-00 RES,CHIP 47 5% 1/10W
R630 1-216-206-00 RES,CHIP 2.2K 5% 1/8W
R631 1-216-073-00 METAL CHIP 10K 5% 1/10W
R632 1-216-089-00 RES,CHIP 47K 5% 1/10W
R633 1-216-089-00 RES,CHIP 47K 5% 1/10W
R634 1-216-081-00 METAL CHIP 22K 5% 1/10W
R640 1-216-206-00 RES,CHIP 2.2K 5% 1/8W
R643 1-216-089-00 RES,CHIP 47K 5% 1/10W
R644 1-216-081-00 METAL CHIP 22K 5% 1/10W
R650 1-216-049-11 RES,CHIP 1K 5% 1/10W
R651 1-216-049-11 RES,CHIP 1K 5% 1/10W
MAIN
