– 50 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R655 1-216-073-00 METAL CHIP 10K 5% 1/10W
R656 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R657 1-216-097-00 RES,CHIP 100K 5% 1/10W
R658 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R659 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R661 1-216-025-00 RES,CHIP 100 5% 1/10W
R662 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R664 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R667 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R669 1-216-025-00 RES,CHIP 100 5% 1/10W
R670 1-216-025-00 RES,CHIP 100 5% 1/10W
R671 1-216-025-00 RES,CHIP 100 5% 1/10W
R672 1-216-025-00 RES,CHIP 100 5% 1/10W
R673 1-216-025-00 RES,CHIP 100 5% 1/10W
R675 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R676 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R680 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R681 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R682 1-216-025-00 RES,CHIP 100 5% 1/10W
R683 1-216-025-00 RES,CHIP 100 5% 1/10W
R701 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R702 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R703 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R704 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R705 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R706 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R707 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R708 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R715 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R731 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R732 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R741 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R742 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R751 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R752 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R761 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R762 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R910 1-216-089-00 RES,CHIP 47K 5% 1/10W
R911 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R912 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R915 1-216-017-00 RES,CHIP 47 5% 1/10W
R916 1-216-089-00 RES,CHIP 47K 5% 1/10W
R917 1-216-081-00 METAL CHIP 22K 5% 1/10W
R931 1-216-049-11 RES,CHIP 1K 5% 1/10W
R941 1-216-049-11 RES,CHIP 1K 5% 1/10W
< VARIABLE RESISTOR >
RV110 1-238-861-11 RES, ADJ, CERMET 470K
RV231 1-238-856-11 RES, ADJ, CERMET 10K
RV241 1-238-856-11 RES, ADJ, CERMET 10K
< SWITCH >
S501 1-571-478-11 SWITCH, SLIDE (POWER SELECT)
S551 1-571-532-21 SWITCH, TACTIL (RESET)
S560 1-762-108-11 SWITCH, PUSH (1 KEY)
(PANEL DETACH DETECT)
< TUNER UNIT >
TU10 A-3282-029-A TUX-006/2(E) (FM/AM TUNER UNIT)
< VIBRATOR >
X10 1-577-126-51 VIBRATOR, CRYSTAL (7.2MHz)
X101 1-579-952-21 VIBRATOR, CERAMIC (8MHz)
X150 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
X501 1-760-489-11 VIBRATOR, CERAMIC (5MHz)
X502 1-760-928-21 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
* 1-665-379-13 SUB BOARD
**********
< CONNECTOR >
CN800 1-779-170-11 SOCKET, CONNECTOR 20P
CN801 1-779-169-11 SOCKET, CONNECTOR 18P
< DIODE >
D800 8-719-422-64 DIODE MA8062-M
D801 8-719-422-64 DIODE MA8062-M
D802 8-719-422-64 DIODE MA8062-M
D803 8-719-422-64 DIODE MA8062-M
< DIODE >
LED800 8-719-058-14 LED CL-220PG-C-TS (TAPE WINDOW)
< SWITCH >
LSW800 1-762-619-11 SWITCH, KEY BOARD (WITH LED) (6)
< TRANSISTOR >
Q800 8-729-424-08 TRANSISTOR UN2111
Q801 8-729-421-22 TRANSISTOR UN2211
< RESISTOR >
R800 1-216-073-00 METAL CHIP 10K 5% 1/10W
R801 1-216-073-00 METAL CHIP 10K 5% 1/10W
R803 1-216-037-00 METAL CHIP 330 5% 1/10W
R804 1-216-049-11 RES,CHIP 1K 5% 1/10W
R805 1-216-049-11 RES,CHIP 1K 5% 1/10W
R806 1-216-049-11 RES,CHIP 1K 5% 1/10W
R807 1-216-049-11 RES,CHIP 1K 5% 1/10W
R808 1-216-089-00 RES,CHIP 47K 5% 1/10W
R809 1-216-089-00 RES,CHIP 47K 5% 1/10W
************************************************************
MISCELLANEOUS
***************
2 1-776-527-41 CORD (WITH CONNECTOR) (ISO) (POWER)
F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) (10A)
HP901 1-500-157-21 HEAD, MAGNETIC (PLAYBACK)
M901 A-3291-665-A MOTOR ASSY, MAIN (CAPSTAN/REEL)
************************************************************
MAIN SUB
